LDS1000 Controller for Laser Diode Sensors
2.3.2 Sensors
Autocollimator, bilingual user’s manual LDS-Vector
Rectitude sensor, bilingual user’s manual STR500-H
2.3.3 Accessories and Additional Equipment Kits
Calibration blade kit, with certificate LDS-CAL01
2-theta adjustable mount LDS-SL
2-theta + XY adjustable mount LDS-SLXY
4 movement adjustable mount on X26 (complete, for LDS-Vector)
LDS-X26-V
2.4 Dimensions
O
I
329.5 (Depth 352)
IEEE-488
RS-232-C
Y & Z
Outputs
Sensor
Connector
– Front View –
– Rear View –
83.5
21
PWOK
Input
TRIG
Input
!
