29
NXAMP4x4
REF NO.
PART NO. DESCRIPTION REMARKS
QTY RANK
-012 -- RESISTOR ARRAY (CHIP) 150x4 J (WG89190)
SW001 -- TACT SWITCH SKRGAED010 VOL-A (WE95200) 01
SW002 -- TACT SWITCH SKRGAED010 VOL-B (WE95200) 01
SW003 -- PUSH SWITCH LS22BB-2UR/UR-T MUTE-CH1 (WK74000)
SW004 -- PUSH SWITCH LS22BB-2UR/UR-T MUTE-CH2 (WK74000)
SW005 -- PUSH SWITCH LS22BB-2UR/UR-T MUTE-CH3 (WK74000)
SW006 -- PUSH SWITCH LS22BB-2UR/UR-T MUTE-CH4 (WK74000)
SW007 -- TACT SWITCH SKRGAED010 SELECT-CH1 (WE95200) 01
SW008 -- TACT SWITCH SKRGAED010 SELECT-CH2 (WE95200) 01
SW009 -- TACT SWITCH SKRGAED010 SELECT-CH3 (WE95200) 01
SW010 -- TACT SWITCH SKRGAED010 SELECT-CH4 (WE95200) 01
* WR777200 CIRCUIT BOARD PAANH (I1209)(X8712G0)
C401 -- MYLAR CAPACITOR 1500pF 50V J (UA65315) 01
C401 -- MYLAR CAPACITOR 1500pF 50V J (UA35315)
C402 -- ELECTROLYTIC CAP. 2.2uF 250V (WJ45880) 01
C403 -- ELECTROLYTIC CAP. 2.2uF 250V (WJ45880) 01
C404 -- CERAMIC CAPACITOR-B (CHIP) 1000pF 50V K (US06310) 01
C405 -- ELECTROLYTIC CAP. 470uF 10V (UU22847) 01
C406 -- CERAMIC CAPACITOR-CH (DISC) 22pF 500V C (WG21170)
C407 -- MYLAR CAPACITOR 4700pF 50V J (UA35347) 01
C407 -- MYLAR CAPACITOR 4700pF 50V J (UA65347) 01
C408 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C409 -- MONOLITHIC CERAMIC CAP. 22pF 630V J (WJ59260) 01
C410 -- ELECTROLYTIC CAP. 10uF 50V (UR86710) 01
C411 -- MONOLITHIC CERAMIC CAP. 22pF 630V J (WJ59260) 01
C412 -- ELECTROLYTIC CAP. 1.0uF 50V (UR86610) 01
C413 -- ELECTROLYTIC CAP. 10uF 50V (UR86710) 01
C414 -- ELECTROLYTIC CAP. 4.7uF 160V (UR80647) 01
C415 -- ELECTROLYTIC CAP. 4.7uF 160V (UR80647) 01
C416 -- MONOLITHIC MYLAR CAPACITOR 0.1uF 50V (VR16830) 01
C417 -- MONOLITHIC MYLAR CAPACITOR 0.1uF 50V (VR16830) 01
C418 -- MONOLITHIC CERAMIC CAP. 22pF 630V J (WJ59260) 01
C419 -- MONOLITHIC CERAMIC CAP. 22pF 630V J (WJ59260) 01
C420 -- MYLAR CAPACITOR 0.01uF 50V J (UA65410) 01
C420 -- MYLAR CAPACITOR 0.01uF 50V J (UA35410) 01
C421 -- MYLAR CAPACITOR 0.01uF 50V J (UA65410) 01
C421 -- MYLAR CAPACITOR 0.01uF 50V J (UA35410) 01
C422 -- ELECTROLYTIC CAP. 2.2uF 250V (WJ45880) 01
C423 -- ELECTROLYTIC CAP. 2.2uF 250V (WJ45880) 01
C424 -- MONOLITHIC CERAMIC CAP. 100pF 250V J (WJ59270) 01
C425 -- MONOLITHIC CERAMIC CAP. 100pF 250V J (WJ59270) 01
C426 -- POLYPROPYLENE CAPACITOR 3.3uF 250V J (WJ45970) 06
C427 -- POLYPROPYLENE CAPACITOR 3.3uF 250V J (WJ45970) 06
C428 -- CERAMIC CAPACITOR (CHIP) 2200pF 250V K (WH15840) 01
C429 -- CERAMIC CAPACITOR (CHIP) 2200pF 250V K (WH15840) 01
C430 -- ELECTROLYTIC CAP. 220uF 25V (WF20450) 01
C431 -- ELECTROLYTIC CAP. 47uF 35V (UR85747) 01
C432 -- ELECTROLYTIC CAP. 10uF 50V (UR86710) 01
C433 -- ELECTROLYTIC CAP. 100uF 35V (UR85810) 01
C434 -- MYLAR CAPACITOR 0.01uF 50V J (UA35410) 01
C434 -- MYLAR CAPACITOR 0.01uF 50V J (UA65410) 01
C435 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C436 -- MONOLITHIC CERAMIC CAP. 100pF 250V J (WJ59270) 01
C437 -- MONOLITHIC CERAMIC CAP. 100pF 250V J (WJ59270) 01
C438 -- ELECTROLYTIC CAP. 100uF 250V (WK58440) 05
C439 -- ELECTROLYTIC CAP. 100uF 250V (WK58440) 05
C440 -- ELECTROLYTIC CAP. 2.2uF 250V (WJ45880) 01
C441 -- ELECTROLYTIC CAP. 2.2uF 250V (WJ45880) 01
C442 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C443 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C444 -- CERAMIC CAPACITOR-B (CHIP) 1000pF 50V K (US06310) 01
C445 -- CERAMIC CAPACITOR-B (CHIP) 1000pF 50V K (US06310) 01
C446 -- CERAMIC CAPACITOR-SL(CHIP) 470pF 50V J (US06247) 01
CN401 -- CONNECTOR, BASE POST PH 5P TE (VB39010) 01
CN403 -- CONNECTOR, BASE POST PH 2P TE (VB38980) 01
D401 -- DIODE 1SS355 TE-17 (VT33290) 01
-403 -- DIODE 1SS355 TE-17 (VT33290) 01
D404 -- ZENER DIODE UDZS3.9B 3.9V (VU17160) 01
D405 -- DIODE (CHIP) HSU83 TRF -E (WD84430)
OPT-AN, PN-AN, RS232-GPI and PAANH
✽ : New Parts RANK: Japan only
