Nexo NXAMP 4X4 Service Manual

20
NXAMP4x4
REF NO.
PART NO. DESCRIPTION REMARKS
QTY RANK
ELECTRICAL PARTS
* WR776500 CIRCUIT BOARD CONTROL (X8710D0)
WJ972600 CIRCUIT BOARD INAN (WJ97320)(X8714C0) 28
* WJ972801 CIRCUIT BOARD OUTANH (WJ97320)(X8714C0) 20
* WT661200 CIRCUIT BOARD NX-DFLT (YC233A0)
WJ971500 CIRCUIT BOARD OPT-AN (WJ97170)(X8711E0) 16
-- CIRCUIT BOARD PN-AN (WJ97170)(X8711E0)(WJ97130) 20
* WJ971401 CIRCUIT BOARD RS232-GPI (WJ97170)(X8711E0) 16
-- CIRCUIT BOARD LCD SPACER (WJ97170)(X8711E0)(WK62420) 08
* WR777200 CIRCUIT BOARD PAANH (WR77710)(X8712G0)
* WJ973501 CIRCUIT BOARD PSANHA J,U (X8715G0) 74
* WJ973601 CIRCUIT BOARD PSANHA CHN (X8715G0) 73
* WJ973801 CIRCUIT BOARD PSANHB J,U (X8715G0) 73
* WJ973901 CIRCUIT BOARD PSANHB CHN (X8715G0) 73
* WR776500 CIRCUIT BOARD CONTROL (X8710D0)
C001 -- MYLAR CAPACITOR (CHIP) 2200pF 50V J (WB57540)
-004 -- MYLAR CAPACITOR (CHIP) 2200pF 50V J (WB57540)
C005 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C006 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C007 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C008 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C009 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C010 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C011 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C012 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C013 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C014 -- CERAMIC CAPACITOR-CH (CHIP) 56pF 50V J (US06156) 01
-017 -- CERAMIC CAPACITOR-CH (CHIP) 56pF 50V J (US06156) 01
C018 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C019 -- ELECTROLYTIC CAP. 22uF 25V (WC89280) 01
-022 -- ELECTROLYTIC CAP. 22uF 25V (WC89280) 01
C027 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-031 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C032 -- ELECTROLYTIC CAP.(CHIP) 100uF 16V (UF03810) 01
C033 -- ELECTROLYTIC CAP.(CHIP) 100uF 16V (UF03810) 01
C034 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C035 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C036 --
ELECTROLYTIC CAPACITOR (CHIP) 1uF 50V (UF06610) 01
C037 --
ELECTROLYTIC CAPACITOR (CHIP) 1uF 50V (UF06610) 01
C038 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
-045 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C046 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
-049 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C050 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-053 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C054 -- CERAMIC CAPACITOR-SL(CHIP) 470pF 50V J (US06247) 01
-061 -- CERAMIC CAPACITOR-SL(CHIP) 470pF 50V J (US06247) 01
C062 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C063 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C064 -- MYLAR CAPACITOR (CHIP) 2700pF 50V J (WB57550)
C065 -- MYLAR CAPACITOR (CHIP) 2700pF 50V J (WB57550)
C066 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C067 -- MYLAR CAPACITOR (CHIP) 2700pF 50V J (WB57550)
C068 -- MYLAR CAPACITOR (CHIP) 2700pF 50V J (WB57550)
C069 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C070 -- CERAMIC CAPACITOR-F (CHIP) 1.0uF 10V Z (US12610) 01
C071 -- CERAMIC CAPACITOR-F (CHIP) 1.0uF 10V Z (US12610) 01
C072 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-075 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C076 -- CERAMIC CAPACITOR-F (CHIP) 1.0uF 10V Z (US12610) 01
C077 -- CERAMIC CAPACITOR-F (CHIP) 1.0uF 10V Z (US12610) 01
C079 -- CERAMIC CAPACITOR-F (CHIP) 1.0uF 10V Z (US12610) 01
C080 -- CERAMIC CAPACITOR-F (CHIP) 1.0uF 10V Z (US12610) 01
C081 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-084 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C085 -- ELECTROLYTIC CAP.(CHIP) 47uF 16V (UF03747) 01
C086 -- ELECTROLYTIC CAP.(CHIP) 47uF 16V (UF03747) 01
C115 -- CERAMIC CAPACITOR-SL (CHIP) 560pF 50V J (US06256) 01
-118 -- CERAMIC CAPACITOR-SL (CHIP) 560pF 50V J (US06256) 01
■ ELECTRICAL PARTS
（電気部品）
✽ : New Parts RANK: Japan only
