Nexo NXAMP 4X4 Service Manual

21
NXAMP4x4
REF NO.
PART NO. DESCRIPTION REMARKS
QTY RANK
C121 -- CERAMIC CAPACITOR-SL (CHIP) 560pF 50V J (US06256) 01
-124 -- CERAMIC CAPACITOR-SL (CHIP) 560pF 50V J (US06256) 01
C131 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-136 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C137 -- MYLAR CAPACITOR (CHIP) 2200pF 50V J (WB57540)
-140 -- MYLAR CAPACITOR (CHIP) 2200pF 50V J (WB57540)
C141 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-150 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C151 -- CERAMIC CAPACITOR-B (CHIP) 1000pF 50V K (US06310) 01
C152 -- CERAMIC CAPACITOR-B (CHIP) 1000pF 50V K (US06310) 01
C153 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-160 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C161 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C162 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C163 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C164 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C165 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C189 -- CERAMIC CAPACITOR-CH (CHIP) 56pF 50V J (US06156) 01
-192 -- CERAMIC CAPACITOR-CH (CHIP) 56pF 50V J (US06156) 01
C193 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C194 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C195 -- CERAMIC CAPACITOR-CH (CHIP) 56pF 50V J (US06156) 01
-198 -- CERAMIC CAPACITOR-CH (CHIP) 56pF 50V J (US06156) 01
C199 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C200 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
-203 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C204 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C205 -- MYLAR CAPACITOR (CHIP) 0.01uF 50V J (WB57620) 01
-212 -- MYLAR CAPACITOR (CHIP) 0.01uF 50V J (WB57620) 01
C213 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
-215 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C216 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-219 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C220 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C221 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
-224 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C225 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C226 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-233 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C234 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C235 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
-242 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C243 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
-245 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C246 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-249 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C250 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C251 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
-254 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C255 -- CERAMIC CAPACITOR-CH(CHIP) 12pF 50V J (US06112) 01
C256 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C257 -- CERAMIC CAPACITOR-CH(CHIP) 12pF 50V J (US06112) 01
C258 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-263 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C264 -- ELECTROLYTIC CAP.(CHIP) 22uF 6.3V (UF01722) 01
C265 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C266 -- CERAMIC CAPACITOR-B (CHIP) 1500pF 50V K (US06315) 01
C267 -- CERAMIC CAPACITOR-B (CHIP) 1500pF 50V K (US06315) 01
C268 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-270 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C273 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C274 -- MONOLITHIC CERAMIC CAP. 10uF 6.3V K (WG96940) 01
-280 -- MONOLITHIC CERAMIC CAP. 10uF 6.3V K (WG96940) 01
C281 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-284 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C285 -- CERAMIC CAPACITOR-B (CHIP) 0.047uF 16V K (US03447) 01
C286 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C289 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C291 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C294 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
