22
NXAMP4x4
REF NO.
PART NO. DESCRIPTION REMARKS
QTY RANK
C296 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-306 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C307 -- ELECTROLYTIC CAP.(CHIP) 100uF 16V (UF03810) 01
C308 -- ELECTROLYTIC CAP.(CHIP) 100uF 16V (UF03810) 01
C309 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C311 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-336 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C337 -- CERAMIC CAPACITOR-B (CHIP) 0.01uF 50V K (US06410) 01
C338 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C339 -- CERAMIC CAPACITOR-F (CHIP) 1.0uF 10V Z (US12610) 01
C341 -- MYLAR CAPACITOR (CHIP) 2200pF 50V J (WB57540)
-344 -- MYLAR CAPACITOR (CHIP) 2200pF 50V J (WB57540)
C345 -- CERAMIC CAPACITOR-B(CHIP) 820pF 50V K (US06282) 01
-348 -- CERAMIC CAPACITOR-B(CHIP) 820pF 50V K (US06282) 01
C349 -- CERAMIC CAPACITOR (CHIP) 120pF 50V J (US06212) 01
-352 -- CERAMIC CAPACITOR (CHIP) 120pF 50V J (US06212) 01
C353 -- ELECTROLYTIC CAP. 22uF 25V (WC89280) 01
-356 -- ELECTROLYTIC CAP. 22uF 25V (WC89280) 01
C357 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C358 -- ELECTROLYTIC CAP.(CHIP) 100uF 16V (UF03810) 01
C359 -- CERAMIC CAPACITOR-F (CHIP) 1.0uF 10V Z (US12610) 01
-362 -- CERAMIC CAPACITOR-F (CHIP) 1.0uF 10V Z (US12610) 01
C363 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C364 -- ELECTROLYTIC CAP. (CHIP) 10uF 50V (UF06710) 01
C367 -- CERAMIC CAPACITOR-B (CHIP) 1000pF 50V K (US06310) 01
-376 -- CERAMIC CAPACITOR-B (CHIP) 1000pF 50V K (US06310) 01
C381 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-384 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
C821 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
-831 -- CERAMIC CAPACITOR-B(CHIP) 0.1uF 50V K (WD96920) 01
CN005 -- P.C.B CONNECTOR HTSS 14P TE (WN05930)
CN006 -- BASE POST CONNECTOR PH 13P (VT38940) 02
CN007 -- CONNECTOR BASE POST PH 11P TE (VT38920) 01
CN008 -- BASE POST CONNECTOR PH 10P TE (VT38910) 01
CN009 -- CONNECTOR 30P TP FFC/FPC (V441510) 02
CN010 -- CONNECTOR 30P TP FFC/FPC (V441510) 02
CN011 -- BASE POST CONNECTOR PH 9P TE (VT38900) 01
CN012 -- BASE POST CONNECTOR PH 5P TE (VT38860) 01
-015 -- BASE POST CONNECTOR PH 5P TE (VT38860) 01
CN016 -- BASE POST CONNECTOR PH 12P (VT38930) 02
CN017 -- CONNECTOR FMN 40P (WC19900)
D001 -- DIODE (CHIP) RB160L-40 TE25 (VS59760) 01
-004 -- DIODE (CHIP) RB160L-40 TE25 (VS59760) 01
D005 -- DIODE SMP100LC-25 (WJ52830)
D006 -- DIODE SMP100LC-25 (WJ52830)
DA001 -- DIODE ARRAY DAN217 0.3A x2 (VV55630) 01
-028 -- DIODE ARRAY DAN217 0.3A x2 (VV55630) 01
DA029 -- DIODE ARRAY DAN217 0.3A x2 (VV55630) 01
-036 -- DIODE ARRAY DAN217 0.3A x2 (VV55630) 01
EM001 -- CHIP EMI FILTER 31PT222Z1E9L TP (VZ58110) 01
EM002 -- CHIP EMI FILTER 31PT222Z1E9L TP (VZ58110) 01
EM003 -- CHIP EMI FILTER 31PT222Z1E9L TP (VZ58110) 01
IC001 -- IC CS3318-CQZ VOLUME CONTROLER (X8486A0)
IC002 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
-005 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
IC006 -- IC NJM78M09DL1A(TE1) REGULATOR (XZ940A0) 02
IC007 -- IC NJM79M09DL1A REGULATOR -9V (X5366A0) 02
IC008 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
-011 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
IC012 -- IC CS4272-CZZR CODEC (X8487A0)
IC013 -- IC CS4272-CZZR CODEC (X8487A0)
IC018 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
-021 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
IC022 -- IC DSPB56371AF180 DSP (X8489A0)
IC023 -- IC DSPB56371AF180 DSP (X8489A0)
IC024 -- IC LD1117STR ADJUSTAB REGULATOR (X8495A0)
IC028 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
-034 -- IC NJM2068M-D(TE2) OP AMP (X3505A0) 02
IC035 -- IC PCM1803ADBR A/D CONVERTER (X7357B0) 03
-038 -- IC PCM1803ADBR A/D CONVERTER (X7357B0) 03
CONTROL
✽ : New Parts RANK: Japan only
