Nexo NXAMP 4X4

NXAMP4x4
8
BACDEFGH
2
1
3
4
5
28CA1-2001022110-50
Input_Amp
(PCB INANH)
Input_VR
(PCB Control)
ADC buffer
(PCB Control)
-14dB
Fixed Gain
0.25dB step
Variable Gain
+6dB
Fixed Gain
NXAMP4x4 LEVEL DIAGRAM
CS3318
3
12
Maximum Input
Voltage
+28.0dBu
CS4272 Codec +DSP
Digital Domain
DAC buffer
(PCB Control)
CS3318
Output_VR
(PCB Control)
Power_Amp
(PCB PAANH)
-0.4dB
Fixed Gain
+37dB
Fixed Gain
0.25dB step
Variable Gain
MAXIMUM
LEVEL
+43.8dBu
+6.8dBu
+5.8dBu+6.2dBu
-0.4dB
+1dB
-96dB
+7.5dBu
+1.5dBu
-4.0dBu
+14.0dBu
-14.0dB
-12.5dB
+5.5dB
+6.0dB
Note:
The solid line shows the gain structure in the analog test mode of the test program.
This level diagram is for the purpose of circuit design only.
The actual gain structure will depend on the firmware that is used.
The broken line shows an example in the setting that allows the maximum input signal level
Sensitivity
+10.0dBu
■ BLOCK DIAGRAM 5/5
（ブロックダイアグラム5/5）
