Nexo NXAMP 4X4 Service Manual

5
NXAMP4x4
REF NO.
PART NO. DESCRIPTION REMARKS
QTY RANK
10 WK668300 MAIN CHASSIS J,U 17
10 WK668400 MAIN CHASSIS CHN 17
20 -- BIND HEAD TAPPING SCREW-B 4x8 MFZN2B3 (WE96200) 4 01
30 WK742900 DC FAN ASSEMBLY AN-PA 417
40 -- BIND HEAD SCREW 4x16 MFZN2W3 SP (WE98400) 8 01
50 -- HEXAGONAL NUT M4 #1 (WG16920) 8
60 WJ972600 CIRCUIT BOARD INAN 28
70 -- BIND HEAD TAPPING SCREW-B 2.6x8 MFZN2B3 (WE96170) 16 01
75 -- INSULATION SHEET PS AN-PA (WM98090)
* 80 WJ973801 CIRCUIT BOARD PSANHB J,U 73
* 80 WJ973901 CIRCUIT BOARD PSANHB CHN 73
90 -- HEXAGONAL SPACER H=81.4 B=5.5 (WK67190) 5
95 -- HEXAGONAL SPACER H=41 B=5.5 (WN00250)
100 -- BIND HEAD TAPPING SCREW-S 3x6 MFZN2W3 (WE87790) 4 01
120 -- CONNECTOR ASSEMBLY PSPS PH&PH 6P (WK66350)
130 -- CONNECTOR ASSEMBLY PH10P C AND C 10P 260 (WK68740)
140 -- CONNECTOR ASSEMBLY 32A POWERCON ASSY J,U (WK66060) 2
140a -- CONNECTOR POWERCON NAC3MP-HC J,U (WK66020)
140 -- CONNECTOR ASSEMBLY ACPS 20A POWERCON ASSY CHN (WK66050) 2
140a -- CONNECTOR POWERCON NAC3MPA CHN (WK66030)
150 -- FLAT HEAD TAPPING SCREW-B 3x8 MFZN2B3 (WF26680) 4
160 -- BIND HEAD TAPPING SCREW-S 4x8 MFZN2W3 (WE94180) 2 01
170 -- DATA LINE FILTER K1 NFT-13BK2 NFT-25 (V312290) 06
180 -- CORD HOLDER T18R TYTIN CO. (V327280) 2
180 -- CORD HOLDER
TYTON T18R L100 W2.5 BLACK (WX11230) 2
185 -- ADHESIVE TAPE 15x30 (WG52680) 09
* 190 WR779100 PA UNIT AN-PA-HIGH 8F28
200 --
CONNECTOR ASSEMBLY SIGPA3H C AND C 5P 420mm (WK17100)
210 -- BIND HEAD TAPPING SCREW-B 4x8 MFZN2B3 (WE96200) 6 01
215 -- ADHESIVE TAPE 15x30 (WG52680) 09
* 220 WR779100 PA UNIT AN-PA-HIGH 8F28
230 --
CONNECTOR ASSEMBLY SIG-PA4 C&C 5P 500mm (WK17110)
240 -- BIND HEAD TAPPING SCREW-B 4x8 MFZN2B3 (WE96200) 6 01
245 -- ADHESIVE TAPE 15x30 (WG52680) 09
* 250 WR779100 PA UNIT AN-PA-HIGH 8F28
260 --
CONNECTOR ASSEMBLY SIG-PA1 C&C 5P 420mm (WK02080) 03
270 -- BIND HEAD TAPPING SCREW-B 4x8 MFZN2B3 (WE96200) 6 01
275 -- ADHESIVE TAPE 15x30 (WG52680) 09
* 280 WR779100 PA UNIT AN-PA-HIGH 8F28
290 --
CONNECTOR ASSEMBLY SIGPA2H C AND C 5P 500mm (WK17090)
300 -- BIND HEAD TAPPING SCREW-B 4x8 MFZN2B3 (WE96200) 6 01
* 310 WJ972801 CIRCUIT BOARD OUTANH 20
313 -- INSULATION SHEET 1 AN-PA (WM14990)
314 -- SHIELD 1 AN-PA (WM14970)
315 -- SHIELD 2 AN-PA (WM14980)
316 -- INSULATION SHEET 2 AN-PA (WM15000)
317 -- PLASTIC RIVET NRP-345 (CB81574) 3 01
320 -- FLAT HEAD TAPPING SCREW-B 3x8 MFZN2B3 (WF26680) 8
325 -- BIND HEAD TAPPING SCREW-S 3x6 MFZN2W3 (WE87790) 01
330 -- BIND HEAD TAPPING SCREW-B 3x8 MFZN2B3 (WE77440) 01
340 -- CONNECTOR ASSEMBLY SENS SENSE (WK02090)
* 350 WJ971401 CIRCUIT BOARD RS232-GPI 16
360 -- FFC ASSEMBLY WK02110,SUMITUBE (WM15830)
370 -- HEXAGONAL LOCK SCREW (WK51890) 4 01
380 -- PS ANGLE 1 (WK67130)
390 -- BIND HEAD TAPPING SCREW-S 3x6 MFZN2B3 (WE87780) 2 01
395 -- GND ANGLE AN-PA-HIGH (WM99350)
396 -- BIND HEAD TAPPING SCREW-S 3x6 MFZN2B3 (WE87780) 01
400 -- PS ANGLE 2 (WK67140) 2
410 -- BIND HEAD TAPPING SCREW-S 3x6 MFZN2W3 (WE87790) 2 01
420 -- CORD HOLDER T18R TYTIN CO. (V327280) 22
420 -- CORD HOLDER
TYTON T18R L100 W2.5 BLACK (WX11230) 22
* 430 WJ973501 CIRCUIT BOARD PSANHA J,U 74
* 430 WJ973601 CIRCUIT BOARD PSANHA CHN 73
440 -- HEXAGONAL SPACER H=50 B=5.5 (WK67200)
450 -- BIND HEAD TAPPING SCREW-S 3x6 MFZN2W3 (WE87790) 9 01
470 -- CONNECTOR ASSEMBLY PH11P C&C 11P 200mm (WK68760) 03
480 -- CONNECTOR ASSEMBLY PH9P C&C 9P 200mm (WK68770)
490 -- DATA LINE FILTER K1 NFT-13BK2 NFT-25 (V312290) 06
500 -- CORD HOLDER T18R TYTIN CO. (V327280) 11
}
✽ : New Parts RANK: Japan only
}
}
