Electrical additional heater
Description of functions - Basic functions
29
FIGHTER 1330
Menu 9.1.8 Additive
Whether additional heat is to be engaged is set
here. The options are: Off, Electricity, Oil or Elec-
tri/Oil. The factory setting is Off.
In order for the electrical additional heater to be
active the option Electricity or Electri/Oil must be
selected in this menu. When Electri/Oil is select-
ed, electricity is used for the additional output
when the input Tariff A (TA) is short-circuited, oth-
erwise oil is used.
Menu 8.2.5 Additive start value
Here you select at which degree-minute setting
the first additional heater step shall start for heat-
ing. The value is adjustable between -3000 and 0.
The factory setting is -500.
Menu 8.2.6 GM for additive step
Here you set how many degree-minutes shall
pass between each additional heater step. The
value is adjustable between 10 and 500. The fac-
tory setting is 100.
Menu 8.3.1 Fuse size
The setting selected on the EBV card (2) knob
(100) is shown here.
Menu 8.3.2 Max electric power
The setting selected on the EBV card (2) knob
(101) is shown here.
Menu 6.2.1 Immersionheater type
Here you select whether immersion heater
control shall take place in binary or linear.
Binary control means that stepping is car-
ried out according to the binary sys-
tem and in doing so makes it possible to
control a maximum of 63 electrical steps.
Linear control gives a maximum of 6 electrical
steps when stepping is carried out according to
the linear increase model.
Menu 6.2.2 Immersionheatrelays
Here you select how many relays are connected
to the electrical additional for heat production.
Adjustable between 1 and 6. The factory setting
is 3.
Menu 6.2.3 Steps at 2h delay
The number of permitted electrical steps within 2
hours of start up. Adjustable between 0 and 63.
The factory setting is 3.
Step ETS-1 ETS-2 ETS-3
0 - - -
1 230 V - -
2 230 V 230 V -
3 230 V 230 V 230 V
Examples of Linear control with 3 relays:
Step ETS-1 ETS-2 ETS-3
0 - - -
1 230 V - -
2 - 230 V -
3 230 V 230 V -
4 - - 230 V
5 230 V - 230 V
6 - 230 V 230 V
7 230 V 230 V 230 V
Examples of Binary control with 3 relays:
Quick guide - menu settings electrical additional heater
The outline diagram with docking instruc-
tions is available at www.nibe.com
