List of components
75
FIGHTER 1330
1 Miniature circuit breaker
2 EBV-card
3 Communication, several FIGHTER 1330s
4 Brine connection, KB-in
5 Brine connection, KB-out
6 Terminal blocks, external units, X6
6 a * Terminal blocks, external units, X6A
6 b * Terminal blocks, external units, X6B
7 a, b Service connection, high pressure
8 Switch, 1 - 0 -
9 Terminal block, incoming electricity, X9
10 * Expansion card 1
11 * Expansion card 2
13 Terminal blocks, pumps, accessories
15 ** Outdoor sensor, connection
16 Heating medium pump, module A
17 a, b Evaporator
18 a, b Condenser
19 Heating medium pump, module B
22 Measure card
26 a, b Motor protection, including reset
27 a, b Compressor
29 Base card
32 Display unit
33 a, b High pressure pressostat
34 CPU-card
35 Brine pump
37 Motor protection device, brine pump
38 Contactor, brine pump
41 a, b Low pressure pressostat
42 a, b Service connection, low pressure
48 a, b Expansion valve
52 ** Safety valve, brine side
60 a, b EMC-Filter
63 ** Particle filter
65 a, b Drying filter
69 a, b Contactor, compressor operation
70 Heating medium flow from module A
71 Connection, heating medium return
72 Heating medium flow from module B
73 Return line from water heater
75 Air vent valve, heating medium system
76 Drain for heating medium system
77 Venting valve, collector system
78 Drain for collector system
79 Temperature sensor, brine out, (KB-utB)
80 Temperature sensor, brine out, (KB-utA)
86 Temperature sensor, brine in, (KB-in)
88 Temperature sensor, heating medium flow,
(VBFB)
89 Temperature sensor, heating medium flow,
(VBFA)
93 Temperature sensor, heating medium return,
(VBRB)
94 The temperature sensor, heating medium
return, (VBRA)
95 Rating plate (see the section Dimensions >
Dimensions and setting out code)
96 Rating plate, cooling section
97 a, b Soft-start relay
100 Knob setting Fuse
101 Knob, setting Max electrical output
102 Knob, setting Max boiler temperature
103 Serial number (see the section Dimensions >
Dimensions and setting out code)
110 Temperature sensor, hot gas temp., cooling
circuit (HG)
111 Temperature sensor, fluid line. temp., cooling
circuit, (VL)
112 Temperature sensor, bulb temp., cooling cir-
cuit, (B)
153 Compressor heater
164 *** Phase sequence monitor
165 Terminal block -X200, compressor heater
* Accessories
** Enclosed
*** Only 30, 40 kW
