Control
FIGHTER 1330
52
A B I II
50.0 C
Hotwatertemperature
13.43
1.0
A B
8.1.1
Menu type
8.1.2
Language
8.1.3
Display contrast
8.1.4
Light intensity
8.1.5
Return to 8.1.0
8.1.0
Display settings
8.2.0
Operatingmodesetting
8.3.0
Load monitor
8.4
Return to 8.0
Other settings
8.0
Changing a parameter (value):
■
Access the required menu.
■
Press the enter button, the numerical value starts
to flash
■
Increase or decrease the value using the plus
respective minus button.
■
Confirm by pressing the enter button.
■
Menu 1.0 is automatically displayed again 30
minutes after pressing the last button.
Example
Changing the Menu type, menu 8.1.1.
■
The starting point is menu 1.0.
■
Press the plus or minus button several times until
menu 8.0 is shown.
■
Press the enter button to move to menu 8.1.0
■
Press the enter button to move to menu 8.1.1
■
Press the enter button to allow the value to be
changed.
■
The value now starts to flash. Change the value
using the plus or minus buttons.
■
Confirm the selected value by pressing the enter
button, the value will then stop flashing.
■
Press the minus button to move to menu 8.1.5
■
Press the enter button to return to menu 8.1.0
■
Press the plus button 3 times to move to menu
8.4
■
Press the enter button to return to menu 8.0
■
Press the plus or minus button several times to
move to menu 1.0
8.2.1
Only additional heat
8.2.2
Changing temperature
8.2.3
Start value compr.
8.2.4
GM for compr.step
8.2.5
Additive start value
8.2.6
GM for additive step
8.2.7
Flow diff HP
8.2.8
Diff HP-Add
8.2.9
Return to 8.2.0
8.3.1
Fuse size
8.3.2
Max electric power
8.3.3
Current phase 1
8.3.4
Current phase 2
8.3.5
Current phase 3
8.3.6
Ratio of transf. EBV
8.3.7
Tariff status
8.3.8
Return to 8.3.0
0.1.1
Status Master:A
0.1.2
Status Master:B
0.1.3
Status Slave 1:A*
0.1.4
Status Slave 1:B*
0.1.5
Status Slave 2:A*
0.1.6
Status Slave 2:B*
0.1.7
Status Slave 3:A*
0.1.8
Status Slave 3:B*
0.1.9
Status Slave 4:A*
0.1.10
Status Slave 4:B*
0.1.11
Status Slave 5:A*
0.1.12
Status Slave 5:B*
0.1.13
Status Slave 6:A*
0.1.14
Status Slave 6:B*
0.1.15
Status Slave 7:A*
0.1.16
Status Slave 7:B*
0.1.17
Status Slave 8:A*
0.1.18
Status Slave 8:B*
0.1.19
Return to 0.1.0
0.0
System
0.2.1
Oper.type Master
0.2.2
Oper.type slave 1
0.2.3
Oper.type slave 2
0.2.4
Oper.type slave 3
0.2.5
Oper.type slave 4
0.2.6
Oper.type slave 5
0.2.7
Oper.type slave 6
0.2.8
Oper.type slave 7
0.2.9
Oper.type slave 8
0.2.10
Return to 0.2.0
0.1.0
Status
0.2.0
Oper.type setting.
0.3
Return to 0.0
N
N
↵
S
N
N
N
N
↵
N
N
N
N
N
N
N
N
N
N
N
N
N
N
S
S
S
S
S
S
S
S
S
S
N
N
* Slaves 1-8 are only shown when made operational
in menu 0.2.x
Normal menus: Displayed in all menu modes.
Extended menus: Only displayed when extended
or service is selected in menu 8.1.1.
Service menus: Only dispalyed when service is
selected in menu 8.1.1
U
S
N
↵
↵
↵
↵
↵
↵
↵
↵
↵
N
↵
↵
N
N
N
N
U
U
U
U
N
N
U
U
U
U
U
U
U
U
U
U
U
U
U
U
U
↵
↵
Changing parameters
