Control
55
FIGHTER 1330
9.1.0
System settings
9.2.0
Floor drying setting
9.3.0
Alarm log
9.4.0
Testing mode
9.5
Return to 9.0
9.1.1
Expansion card 1
9.1.2
Expansion card 2
9.1.3
RCU
9.1.4
Sub shunt
9.1.5
Pool
9.1.6
Hot water acc. tank
9.1.7
Fixed condensing
9.1.8
Additive
9.1.9
Extra collector
9.1.10
Cooling
9.1.11
Room control mode
9.1.12
HW with additional heat
9.1.13
Return to 9.1.0
9.2.1
Op-mode floor drying
9.2.2
Floor drying day
9.2.3
Nos. of days per. 1
9.2.4
Temperature per. 1
9.2.5
Nos. of days per. 2
9.2.6
Temperature per. 2
9.2.7
Return to 9.2.0
9.3.1.0 - 9.3.6.0
Alarm 1 - 6
9.3.7
Clear the alarm log
9.3.8
Return to 9.3.0
Service menues
9.0
9.4.1
Force control
9.4.2
Relay card
9.4.3
Relay 1-8
9.4.4
Relay 9-14
9.4.5
Return to 9.4.0
9.3.x.1
Type of alarm
9.3.x.2
Heat pump
9.3.x.3
Date
9.3.x.4
Time
9.3.x.5
Outdoor temperature
9.3.x.6
Hot watertempe-
rature
9.3.x.7
Flow temperature.
9.3.x.8
Heating flow/return
9.3.x.9
Brine in/out
9.3.x.10
Hot gas temperature
9.3.x.11
Overheating temp.
9.3.x.12
Liquide line temp.
9.3.x.13
Relay status 1-8
9.3.x.14
Relay status 9-14
9.3.x.15
Compressor status
9.3.x.16
Return to 9.3.x.0
S
↵
↵
↵
↵
↵
↵
↵
S
↵
S
↵
↵
↵
↵
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
Main menus
Menu 1.0 Hotwater temperature
The current water temperature (VVG) is shown here.
Menu 2.0 Flow temperature
The current flow temperature (FG) for the heating sys-
tem is shown here with the calculated flow tempera-
ture in brackets.
Menu 4.0 Outdoor temperature
The current outdoor temperature is shown here. Mea-
sured via the outdoor sensor (UG).
Menu 5.0 Heat pump
Values can be read and various settings can be
made concerning each connected heat pump from
these sub-menus.
Menu 8.0 Other settings
Settings regarding the menu type, language, opera-
ting settings and load monitor reading are made in the
sub-menus to this menu.
Menu 9.0 Service menus
This menu and its sub-menus are only shown when
access has been selected in menu 8.1.1.
Values can be read and various settings can be
made from these sub-menus. NOTE! These settings
should only be made by persons with the neces-
sary expertise.
54.1°C
Hotwater temperature
1.0
31.7(28.0)°C
Flow temperature
2.0
Menu 3.0 Flow temperature 2*
The current flow temperature (FG2) for the heating
system is shown here with the calculated flow tempe-
rature in brackets. This menu is first shown when “To”
been selected in menu 9.1.4.
25.7(24.0)°C
Flow temperature 2
3.0
10.3°C
Outdoor temperature
4.0
Heat pump
5.0
Menu 7.0 Clock
Settings regarding the date and time are made in the
sub-menus of this menu. Even different temperature
reductions and increases at selected times are set
from this menu.
Service menus
9.0
Other settings
8.0
Clock
7.0
Menu 0.0 System
Here the current status of the various heat pump
modules are shown and settings concerning Master or
Slave can also be made.
System
0.0
N
N
Menu 6.0 External units
Values can be read and various settings can be made
from these sub-menus. Many of the sub-menus to 6.0
require accessories.
External units
6.0
N
N
N
S
N
N
N
N
* Accessories
A B I II
50.0 C
Hotwatertemperature
13.43
1.0
A B
Normal menus: Displayed in all menu modes.
Extended menus: Only displayed when extended
or service is selected in menu 8.1.1.
Service menus: Only dispalyed when service is
selected in menu 8.1.1
U
S
N
To Next Page
