Control
FIGHTER 1330
58
2.0 Flow temperature
U
U
N
N
N
U
U
U
U
U
U
U
U
U
U
Menu 2.6.0 Own curve definition
Your own curve definition is chosen here. This is
an individual linear curve with one break point. You
select a break point and the associated tempera-
tures. NOTE! The Curve slope in menu 2.1 must be
set to Own curve to activate this.
Menu 2.6.1 Flow temp. at -20 ºC
The flow temperature is selected here with at an
outdoor temperature of -20 °C. The value is adjust-
able between 10 and 80 °C. The factory setting is
55 °C.
Menu 2.6.2 Flow temp. at +20 ºC
The flow temperature is selected here with at an
outdoor temperature of +20 °C. The value is adjust-
able between 10 and 80 °C. The factory setting is
18 °C.
Menu 2.6.3 Set buckling temp.
Here you select at what outside temperature the
break point shall occur. The value is adjustable
be-tween -15 and +15 °C. The factory setting is
0 °C.
Menu 2.6.4 Flowtemp. at buckling
You set the required flow temperature for the break
point here. The value is adjustable between 10 and
80 °C. The factory setting is 40 °C.
Menu 2.6.5 Return
Pressing the enter button returns you to menu
2.6.0.
Menu 2.7.0 Fixed condensing
Pressing the enter button takes you to the sub-
menus, which show the settings for fixed condens-
ing. Only shown when fixed condensing is selected
in menu 9.1.7.
Menu 2.7.1 Starttemp.compressor
Temperature on the flow line sensor (FG) when first
compressor starts. The value is adjustable between
5 and 60 °C. The factory setting is 47 °C.
Menu 2.7.2 Stoptemp. compressor
Temperature on the flow line sensor (FG) when
the last compressor stops. The value is adjustable
between 5 and 60 °C. The factory setting is 50 °C.
Menu 2.7.3 Starttemp. additive
Temperature on the flow line sensor (FG) when
additional heating engages. The value is adjustable
between 5 and 60 °C. The factory setting is 45 °C.
Menu 2.7.4 Stoptemp. additive
Temperature on the flow line sensor (FG) when
additional heating disengages. The value is adjust-
able between 5 and 60 °C. The factory setting is
49 °C.
Menu 2.7.5 Return
Pressing the Enter button returns you to menu
2.7.0.
Menu 2.8 Return temperature
The current temperature of the return water (RG)
from the heating system is shown here.
Menu 2.9 Degree minutes
Current value for number of degree-minutes. This
value can be changed to e.g. accelerate the start
of heat production. The value is adjustable in incre-
ments of 10.
Menu 2.10 Return
Pressing the Enter button returns you to menu 2.0.
Normal menus: displayed in all menu modes.
Extended menus: Only displayed when extended
or service is selected in menu 8.1.1.
Service menus: Only displayed when service is
selected in menu 8.1.1.
U
S
N
