Control
FIGHTER 1330
70
Menu 8.3.0 Load monitor
Pressing the enter button takes you to sub-menus
where readings and settings concerning the load
monitor are made.
Menu 8.3.1 Fuse size
The setting (16, 20, 25, 35, 50 or 63 A) selected on
the EBV-card (2) knob (100) is shown here.
Menu 8.3.2 Max electric power
The setting (variable between 10 and 100 %)
selected on the EBV-card (2) knob (101) is shown
here.
Menu 8.3.3 - 8.3.5 Current phase 1-3
Shows the measured current from the current sen-
sor, phase 1 - 3.
When the current falls below 2.0 A, low is shown
on the display.
Menu 8.3.6 Ratio of transf. EBV
The transfer value must be defined depending on
the current transformers used for the EBV card.
This is done in this menu. The value is adjustable
between 100 and 900 in increments of 10. The set-
ting 300 applies for the supplied current transform-
ers. The factory setting is 300.
Menu 8.3.7 Tariff status
Shows the current tariff status.
Menu 8.3.8 Return
Pressing the enter button returns you to menu
8.3.0.
Menu 8.4 Return
Pressing the Enter button returns you to menu 8.0.
8.0 Other settings
U
N
U
U
U
U
U
U
Menu 8.2.0 Operatingmodesetting
Pressing the enter button takes you to sub-menus
for the operating mode settings.
Menu 8.2.1 Only additional heat
You select here whether additional mode should be
activated. Can be set to Yes or No. When additional
mode is activated the compressors are blocked and
additional heating and circulation pump can not be
blocked using the operating mode button. The fac-
tory setting is No.
Menu 8.2.2 Changing temperature
At this average outdoor temperature, the heat
pump changes operating mode when auto mode is
selected. The value is adjustable between 10 and
40 °C. The factory setting is 25 °C.
Menu 8.2.3 Start value compr.
Here you select at which degree minute setting the
first compressor shall start for heating. The value
is adjustable between -3000 and +100. The factory
setting is -60.
Menu 8.2.4 GM for compr.step
Here you set how many degree-minutes shall pass
between each compressor stage. The value is
adjustable between 0 and 500. The factory setting
is 60.
Menu 8.2.5 Additive start value
Here you select at which degree-minute setting the
first additional heater step shall start for heating.
The value is adjustable between -3000 and 0. The
factory setting is -500.
Menu 8.2.6 GM for additive step
Here you set how many degree-minutes shall pass
between each additional heater step. The value is
adjustable between 10 and 500. The factory setting
is 100.
Menu 8.2.7 Flow diff HP
The largest deviation from the calculated flowtem-
perature before forced control comes into effect is
set here. The value is adjustable between 1 and
20 °C. The factory setting is 13 °C.
Menu 8.2.8 Diff HP-Add
When the current flow temperature differs from
that calculated by this value plus the value in menu
8.2.7, a further additional step is force connected
or disconnected. The value is adjustable between 1
and 20 °C. The factory setting is 3 °C.
Menu 8.2.9 Return
Pressing the enter button returns you to menu
8.2.0.
U
U
U
U
U
U
U
U
U
U
Normal menus: displayed in all menu modes.
Extended menus: Only displayed when extended
or service is selected in menu 8.1.1.
Service menus: Only displayed when service is
selected in menu 8.1.1.
U
S
N
