Control
73
FIGHTER 1330
Menu 9.3.x.10 Hot gas temperature
Shows the hot gas temperature on sensor (HGA/B)
when the alarm tripped.
Menu 9.3.x.11 Overheating Temp.
Shows the bulb temperature for the compressor
module in question on sensor (BA/B) when the alarm
tripped.
Menu 9.3.x.12 Liquide line temp.
Shows the fluid line temperature on sensor (VLA/B)
for the compressor module in question when the
alarm tripped.
Menu 9.3.x.13 Relay status 1-8
Shows the relay status for relay 1 - 8 (relay 1 to the
far left) when the current alarm tripped.
Menu 9.3.x.14 Relay status 9-14
Shows the relay status for relay 9 - 14 (relay 9 to the
far left) when the current alarm tripped.
Menu 9.3.x.15 Compressor status
Shows the compressor status at the time of the
alarm. E. g. Off / Hot water / Heat/cold / Pool.
Menu 9.3.x.16 Return
Pressing the enter button returns you to
menu.9.3.x.0.
Menu 9.3.7 Clear the alarm log
Select Yes to clear the alarm log.
NOTE! The setting returns to No as soon as the
heat pump has implemented the action.
Menu 9.3.8 Return
Pressing the enter button returns you to menu
9.3.0.
Menu 9.4.0 Testing mode
Pressing the enter button takes you to sub-menus
that can be used during installation to check that
the correct connection has been carried out.
Menu 9.4.1 Force control
When this menu is set to On, the user temporar-
ily takes control of the relays on the selected relay
card (menu 9.4.2) in the heat pump the action was
taken on. The setting automatically returns to Off,
30 minutes after the last button was pushed or after
a restart.
Menu 9.4.2 Relay card
The relay card to be force operated is selected here
(Base card, Exp.card 1 or Exp.card 2). Only Base
card can be selected on Slave units. This is also
valid for Master units where no expansion card has
been installed.
Menu 9.4.3 Relay 1-8
Shows the relay status for relay 1 - 8 (relay 1 to
the far left). It is possible to force the relay to the
required position using the enter button. The menu
is only shown when menu 9.4.1 is set to On.
Menu 9.4.4 Relay 9-14
Shows the relay status for relay 9 - 14 (relay 9 to
the far left). It is possible to force the relay to the
required position using the enter button. The menu
is only shown when menu 9.4.1 is set to On.
Menu 9.4.5 Return
Pressing the enter button returns you to menu
9.4.0.
Menu 9.5 Return
Pressing the Enter button returns you to menu 9.0.
9.0 Service menus
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
NOTE!
Incorrect management of the menus
below can seriously damage the heat
pump!
Normal menus: displayed in all menu modes.
Extended menus: Only displayed when extended
or service is selected in menu 8.1.1.
Service menus: Only displayed when service is
selected in menu 8.1.1.
U
S
N
