FIGHTER 360P
For the Installer
Control30
1.0 Temp. HW-sensor 2.0 Flow temperature
Menu 1.1 Temp. compr.sensor
Shows the current temperature on the compressor
sensor (94).
Menu 1.2 Temp. el. heat.sens.
Shows the current temperature on the immersion
heater (88).
50.0°C
Temp. compr.sensor
1.1
45.0°C
Temp. el. heat.sens.
1.2
Menu 1.3 Interval per. XHW
How often the hot water temperature is increased from
the normal level to the extra hot water level is chosen
here. The value is adjustable between 1 and 90 days, or
Off.
Menu 1.4 Stop temperature XHW
The required stop temperature for extra hot water is set
here. The value is adjustable between 56 and 65 °C.
14 days
Interval per. XHW
1.3
60°C
Stop temperature XHW
1.4
Menu 1.5 Return
Return to Menu 1.0.
Return
1.5
Menu 2.4 Max. flow temp.
The set maximum level for the supply temperature to
the heating system is shown here.
The calculated flow temperature never exceeds the
set level irrespective of the outdoor temperature, curve
slope or offset heating curve.
The value is adjustable between 10 and 65 °C.
Menu 2.1 Heating curve
The curve slope for heating curve is chosen here. The
value can be set between curve 1 and 15.
Menu 2.2 Offset heating curve
The selected heating curve offset is shown here. The
value is adjustable between -10 and +10. NOTE! The
value is changed using the Offset heating curve knob.
Menu 2.3 Min. flow temp.
The set minimum level for the supply temperature to
the heating system is shown here.
The calculated flow temperature never drops below
the set level irrespective of the outdoor temperature,
curve slope or offset heating curve.
The value is adjustable between 10 and 65 °C.
55°C
Max. flow temp.
2.4
5
Heating curve
2.1
0
Offset heating curve
2.2
15°C
Min. flow temp.
2.3
U
U
N
N
N
N
N
U
U
