FIGHTER 360P
Control
31
For the Installer
3.0 Flow temperature 22.0 Flow temperature
Menu 2.5 External adjustment
Connecting an external contact, see Electrical con-
nections - External contacts, for example, a room ther-
mostat (RT10, accessory) or a timer allows you to
temporarily or periodically raise or lower the room tem-
perature. When the external contact is made, the heat-
ing curve offset is changed by the number of steps
shown here. The value is adjustable between
-10 and +10.
0
External adjustment
2.5
U
Menu 2.6 Return temperature
The current temperature of the return water from the
heating system on the sensor (93) is shown here.
32.4°C
Return temperature
2.6
U
Menu 2.7 Return
Return to Menu 2.0.
Return
2.7
Menu 3.4 Max. flow temp. 2
The set maximum level for flow temperature 2 to the
heating system is shown here.
The calculated flow temperature never exceeds the
set level irrespective of the outdoor temperature, curve
slope or offset heating curve.
The value is adjustable between 10 and 65 °C.
Menu 3.1 Heating curve 2
The curve slope for heating curve 2 is chosen here.
The value can be set between curve 1 and 15.
Menu 3.2 Offset heat. curve 2
The offset heating curve 2 is chosen here. The value is
adjustable between -10 and +10.
Menu 3.3 Min. flow temp. 2
The set minimum level for flow temperature 2 to the
heating system is shown here.
The calculated flow temperature never drops below
the set level irrespective of the outdoor temperature,
curve slope or offset heating curve.
The value is adjustable between 10 and 65 °C.
55°C
Max. flow temp. 2
3.4
5
Heating curve 2
3.1
0
Offset heat. curve 2
3.2
15°C
Min. flow temp. 2
3.3
U
U
N
N
N
