FIGHTER 360P
For the Installer
Control32
3.0 Flow temperature 2
Menu 3.5 External adjustment2
Connecting an external contact, see Electrical con-
nections - External contacts, for example, a room ther-
mostat (RT10, accessory) or a timer allows you to
temporarily or periodically raise or lower the room tem-
perature. When the external contact is made, the heat-
ing curve 2 offset is changed by the number of steps
chosen. The value is adjustable between -10 and +10.
0
External adjustment2
3.5
U
Menu 3.6 Return temperature 2
The current temperature of the return water from heat-
ing system 2 is shown here.
32.4°C
Return temperature 2
3.6
U
Menu 3.7 Return
Return to Menu 3.0.
Return
3.7
4.0 Outdoor temperature
Menu 4.2 Return
Return to Menu 4.0.
Menu 4.1 Medium outdoor temp.
The average outdoor temperature over the last 24
hours.
Return
4.2
7.4°C
Medium outdoor temp.
4.1
N
N
N
Menu 5.1 Vented air temp.
The current extract air temperature is shown here. This
is the temperature of the ventilation air when it has
passed the heat pump. Measured by sensor (87).
Menu 5.2 Exhaust air temp.
The current exhaust air temperature is shown here. This
is the temperature of the ventilation air before it passes
the heat pump. Measured by sensor (92).
5.0°C
Vented air temp.
5.1
20.4°C
Exhaust air temp.
5.2
Menu 5.3 Stoptime defrosting
The required defrosting time is set here, i.e. the time
that the compressor is at a standstill so that evapora-
tor defrosting can take place when necessary. The
value is adjustable between 15 and 25 minutes.
15 min
Stoptime defrosting
5.3
N
N
U
5.0 Evaporating temperature
