Nice MOONCLEVER MC424 User Manual

10 – English
WARNINGS:•Alltechnicalcharacteristicsstatedrefertoanambienttemperatureof20°C(±5°C).•NiceS.p.areservestherighttomodifytheproductatany
timee, while maintaining the same functionalities and intended use.
Mains power supply MC424Controlunits: 230V
~±10%50÷60Hz
 MC424/V1Controlunits: 120V~±10%50÷60Hz
Max absorbed power 170W
Emergency power supply forPS124bufferbatteries
and for Solemyo solar kit
Maximum motor current: 3A(witha“level6”currentsensitivitycutin)
Service power output 24V
200mAmaximumcurrent(thevoltagecanvaryfrom16to33V )
Phototest Output 24V
100mAmaximumcurrent(thevoltagecanvaryfrom16to33V )
Flashing lamp output forashinglamp24V
,maximumpower25W(thevoltagecanvaryfrom16to33V )
Gate open indicator output forindicatorlampsat24V
maximumpower5W(thevoltagecanvaryfrom16to33V )
or electric locks 12V~25W
STOP Input  forNCcontactsorconstantresistance8,2KΩ+/-25%
Working time automatic detection
Pause time programmableat5,10,20,40,80seconds
Discharge time programmableto0,0.3,0.7,1.3,2seconds
Leaf delay in open cycle programmableat5,10,20,30and40%ofworkingtime
Leaf delay in close cycle automatic detection
1st motor output forWingoWG4024-WG5024
2nd motor output forWingoWG4024-WG5024
Max. cable length powersupply 30m
Solemyo solar power kit 3 m
 motors 10m
 otherinputs/outputs 30m
ashinglight 10m
SCA 30m
 electriclock 10m
 aerial 20m (recommended less than 3 m)
Radio receiver “SM”typecouplingforreceiversSMXI,SMXIS,OXI(ModeIandModeII)
Temperatura di esercizio from-20to50°C
Protection rating IP54withenclosureintact
Dimensions (mm) 310x232xH122
Weight (kg) 4,1
TECHNICAL CHARACTERISTICS OF THE PRODUCT
EN
CE declaration of conformity
Declaration in accordance with the following Directives: 2004/108/EC (EMC); 2006/42/EC (MD) annex II, part B
Note - The content of this declaration corresponds to that specied in the ofcial document deposited at the Nice S.p.A. headquarters and, in particular, to the latest revised edition
available prior to the publishing of this manual. The text herein has been re-edited for editorial purposes. A copy of the original declaration can be requested from Nice S.p.A. (TV) I
.
Number:296/MC424  Revision: 3 Language: EN
Manufacturer’s Name: Nice s.p.a.
Address: ViaPezzaAlta13,Z.I.Rustignè,31046Oderzo(TV)Italy
Person authorised to compile
the technical documentation: Nice s.p.a.
Type of product:  Two24Vdcmotorcontrolunit
Model / Type: MC424
Accessories: SMXI, SMXIS radio receiver
TheundersignedMauroSordini,asChiefExecutiveOfcer,herebydeclaresunderhisownresponsibilitythattheproductidentiedabovecomplieswiththe
provisions of the following directives:
•DIRECTIVE2004/108/ECOFTHEEUROPEANPARLIAMENTANDCOUNCILof15December2004ontheapproximationofthelawsofMemberSta-
tesrelatingtoelectromagneticcompatibilityandrepealingDirective89/336/EEC,inaccordancewiththefollowingharmonisedstandards: 
EN61000-6-2:2005,EN61000-6-3:2007+A1:2011
In addition, the product conforms to the following directive in accordance with the provisions applicable to partly completed machinery:
Directive2006/42/ECOFTHEEUROPEANPARLIAMENTANDCOUNCILofMay172006regardingmachinesandamendingdirective95/16/EC(consoli-
datedtext)
•IherebydeclarethatthepertinenttechnicaldocumentationhasbeendraftedinaccordancewithAnnexVIIBofDirective2006/42/ECandthatthefollowingessentialrequirements
havebeenfullled:1.1-1.1.2-1.1.3-1.2.1-1.2.6-1.5.1-1.5.2-1.5.5-1.5.6-1.5.7-1.5.8-1.5.10-1.5.11
•Themanufactureragreestosendthenationalauthoritiesanypertinentinformationonpartly-completedmachinery,inresponsetoamotivatedrequest,withoutaffectingitsintel-
lectual property rights.
•IfthepartlycompletedmachineryisoperatedinaEuropeancountrywithanofciallanguageotherthanthelanguageusedinthisdeclaration,theimportermustincludeatran-
slation with this declaration.
•ThepartlycompletedmachinerymustnotbeoperateduntilthenalmachineinwhichitistobeincorporatedisdeclaredtoconformtotheprovisionsofDirective2006/42/EC,
if applicable.
Theproductalsocomplieswiththefollowingstandards:
EN60335-1:2002+A1:2004+A11:2004+A12:2006+A2:2006+A13:2008+A14:2010+A15:2011,EN60335-2-103:2003+A11:2009
All parts of the product subject to the following standards comply with them:
EN13241-1:2003+A1:2011,EN12445:2002,EN12453:2002,EN12978:2003+A1:2009
Oderzo,30July2014 Mr.MauroSordini(ChiefExecutiveOfcer)
