4 – English
- End of the procedure with memorisation of all measurements.
All these phases must take place one after the other without any interference
from the operator. If the procedure does not continue correctly, it must be
interruptedwiththeP1button.Repeattheprocedure,modifyingsomeparam-
eters if necessary, for example the current sensitivity cut-in thresholds (see
chapter5).
Thesearethemostimportantphasesofautomationset-upforensuringmaxi-
mumsystemsafety.Thetestcanalsobeperformedasaperiodiccheckof
automationdevices.Testingandcommissioningoftheautomationmustbe
performedbyskilledandqualiedpersonnel,whoareresponsibleforthetests
required to verify the solutions adopted according to the risks present, and for
ensuring observance of all legal provisions, standards and regulations, and in
particularallrequirementsofthestandardEN12445,whichestablishesthetest
methods for checking automations for doors and gates.
Theadditionaloroptionaldevicesmustundergoaspecictestforfunctional-
ity and correct interaction with MC424. Refer to the instruction manuals of the
individual devices.
3.1 - Testing
Thetestingsequencereferstothecontrolunitprogrammedwiththepreset
functions.Seeparagraph5.1:
•MakesurethattheactivationoftheSTEP-BY-STEPinputgeneratesthefol-
lowingsequenceofmovements:“Open,Stop,Close,Stop”.
•MakesurethattheactivationoftheAUXinput(Type1partialopeningfunc-
tion)managesthe“Open,Stop,Close,Stop”sequenceofthemotorofthe
upper leaf only, while the motor of the lower leaf remains in the closed posi-
tion.
• Perform an opening manoeuvre and check that:
- thegatecontinuestheopeningmanoeuvrewhenPHOTOisengaged
- theopeningmanoeuvrestopswhenPHOTO1isengagedandonlycontinues
whenPHOTO1isdisengaged
- ThemanoeuvrestopswhenPHOTO2(ifinstalled)isengagedandtheclosing
manoeuvre starts
• Make sure that the motor switches off when the door reaches the mechanical
stop.
• Perform an opening manoeuvre and check that:
- ThemanoeuvrestopswhenPHOTOisengagedandtheopeningmanoeuvre
starts
- ThemanoeuvrestopswhenPHOTO1isengagedandtheopeningmanoeu-
vrestartsagainwhenPHOTO1isdisengaged
- thegatecontinuestheclosingmanoeuvrewhenPHOTO2isengaged
•CheckthatthestoppingdevicesconnectedtotheSTOPinputimmediately
stop all movement.
• Check that the level of the obstacle detection system is suitable for the appli-
cation:
- During both the opening and the closing manoeuvres, prevent the leaf from
moving by placing an obstacle and check that the manoeuvre inverts before
exceeding the force set down by law
•Otherchecksmayberequireddependingonwhichdevicesareconnectedto
the inputs.
Warning – If an obstacle is detected as moving in the same direction for
2 consecutive manoeuvres in the same direction, the control unit par-
tially inverts both motors for just 1 second. At the following command,
the leafs begin the opening manoeuvre and the rst current sensitiv-
ity cut-in for each motor is considered as a mechanical stop during
the opening cycle. The same happens when the mains power supply is
switched on: the rst command is always an opening manoeuvre and
the rst obstacle is always considered as a mechanical stop during the
opening cycle.
3.2 - Commissioning
Commissioning can only be performed after positive results of all test
phases.
1 Prepare the automation technical documentation, which must contain the
following documents: overall drawing of the automation, electrical wiring
diagram, risk assessment and relative solutions adopted (refer to the rel-
evant forms on our website www.niceforyou.com),manufacturer’sdec-
laration of conformity for all devices used and installer’s declaration of con-
formity.
2 Afxadataplateonthegate,specifyingatleastthefollowingdata:typeof
automation, name and address of manufacturer (responsible for commis-
sioning),serialnumber,yearofconstructionandCEmark.
3 Before commissioning the automation, ensure that the owner is adequately
informed of all associated risks and hazards.
TESTING AND COMMISSIONING
3
ThediagnosticsLEDP2(fig. 2)indicatesanyproblemsormalfunctions
re vealed by the control unit during the manoeuvre.
Asequencewithacertainnumberofashesindicatesthetypeofproblemand
remainsactiveuntilthefollowingmanoeuvrebegins.Thetablebelowsumma-
rises this information:
Number Type of malfunction
Led P2 ashes
1 M1currentsensitivitydevicetriggering
2 M2 current sensitivity device triggering
3 STOPinputcut-induringthemanoeuvre
4 Phototest error
5 Outputovercurrentgateopenindicatororelectriclock
DIAGNOSTICS
4
TheMC424controlunitfeaturessomeprogrammablefunctions.Thesefunc-
tions are pre-set in a typical configuration which satisfies most automatic
systems.Thesefunctionscanbechangedatanytime,bothbeforeandafter
searching automatically for limit switches, by carrying out the relevant program-
mingprocedure;seeparagraph5.3.
5.1 - Preset functions
• Motor movement: fast
• Automatic closing: enabled
• Condominium function: disabled
•Pre-ashing disabled
• Close after photo: disabled
•Openingdelay: level2(10%)
•Everythinginstandby/Phototest: Everythinginstandby
•Gateopenindicator/ElectricLock: Gateopenindicator
•STOPinput: NCtype
• Heavy gates: disabled
• Proportional gate open indicator: disabled
•Pausetime: 20seconds
•Auxiliaryinput: type1partialopening(onlythe 
 upperleafmotorisactivated)
• Current sensitivity: Level 2
5.2 - Programmable functions
Toensurethesystemisbestsuitedtotheuser’srequirements,andsafeinthe
various different conditions of use, the MC424 control unit offers the possibil-
ity to programme several functions or parameters, as well as the function of a
number of inputs and outputs.
5.2.1 - Direct programming
• Slow/rapid movement: Theusercanchoosethespeedofmovementof
thegate,atanytime(withthemotorarrested)simplybyoperatingtheP3key
(g. 2)atanytimethecontrolunitisnotbeingprogrammed.IfLEDL3isoff,
this shows that the slow movement has been set, if on the fast one has.
5.2.2 - Level one programming: part one
• Automatic closing: Thisfunctionfeaturesanautomaticclosingcycleafter
theprogrammedpausetime;thepausetimeisfactorysetto20secondsbut
itcanbemodiedto5,10,20,40or80seconds.
If the function is not activated, the system will run “semi-automatically”.
• “Condominium” function: Thisfunctionisusefulwhentheautomaticsys-
tem is radio-commanded by many different people. If this function is active,
each command received triggers an opening manoeuvre that cannot be
interrupted by further commands. If the function has been deactivated, a
commandcauses:OPEN-STOP-CLOSE-STOP.
• Pre-ashing: Thisfunctionactivatestheashinglightbeforethemanoeuvre
begins for a time that can be programmed to 3 seconds.
 Ifthefunctionisdisabled,thelightwillstartashingwhenthemanoeuvre
starts.
• Close after photo: During the automatic closing cycle, this function reduces
thepausetimeto4secondsafterthePHOTOphotocellhasdisengaged,i.e.
the gate closes 4 seconds after the user has passed through it. If the function
is disabled, the whole programmed pause time will pass.
• Opening delay: During opening, this function causes a delay in the activa-
PROGRAMMING
5
EN
