2 – English

•Activationofthe“PHOTO1”pairofphotocellsstopsboththeopeningand

closing manoeuvres.

•Activationofthe“PHOTO2”pairofphotocells(connectedtothesuitablypro-

grammedAUXinput)hasnoeffectduringclosingwhiletheyinvertmovement

during opening.

Tocheckthepartsofthecontrolunitseeg.2.

Key to g. 2:

A. 24Vpowersupplyconnector

B. M1motorconnector

C. PS124bufferbatteryconnector/Solemyosolarenergysupply

 system(forfurtherdetailsseechapter6.3)

D. 500mAFtypeservicesfuse

E. SelectorswitchfordelayingtheopeningofmotorM1orM2

F. M2 motor terminal

G. Flashing light output terminal

H. Gate open indicator or electric lock output terminal

I. 24Vdcterminalsforservicesandphototest

L. Input terminals

L1…L5. Input and programming LEDs

M. Terminalforradioaerial

N. “SM” radio receiver connector

O. Programming/diagnosticsconnector

P1, P2, P3. Programming buttons and LEDs

2.1 - Preliminary checks for installation

Before proceeding with installation, check the condition of the product compo-

nents, suitability of the selected model and conditions of the intended installa-

tion environment:

• Ensure that all conditions of use remain within the limits of product application

andwithinthe“Producttechnicalspecications”.

• Ensure that the selected installation environment is compatible with the over-

all dimensions of the product (g. 3).

• Ensure that the selected surfaces for product installation are solid and guar-

anteeastablexture.

•Makesurethatthexingzoneisnotsubjecttoooding.Ifnecessary,mount

the product raised from the ground.

• Ensure that the space around the product enables easy and safe completion

of manual manoeuvres.

• Make sure that the automation is provided with mechanical stops on both

closing and opening.

2.2 - Product application limits

TheproductmaybeusedexclusivelywithWG4024,WG5024,XME2024,

TN2020,TN2020L,TOO3024,TOO4524 gearmotors.

2.3 - Installation

Toinstallthecontrolunit,proceedasshowning. 4. Also observe the follow-

ing warnings:

•Thecontrolunitissuppliedinanenclosurethatifcorrectlyinstalledassures

anIP54protectionrating.Thecontrolunitisthereforesuitableforinstallation

outdoors.

•Fixthecontrolunittoaat,vertical,non-removablesurfacethatisadequately

protected from potential impacts. Important!–Thebottomofthecontrolunit

mustbeatleast40cmfromtheground.

• Insert the dedicated cable clamps or pipe glands into the lower part of the

enclosure (g. 4).Important! – If the cable protection tubes end in a pit, it is

likely that condensation will form inside the control unit, which will damage the

electronic board. In this case, protect the control unit adequately so as to pre-

vent the formation of condensation.

•Thecableclampscanbeinsertedonthelongsideoftheenclosureonlyifthe

control unit is installed in a protected indoor environment.

Toinstalltheotherdevicespresentintheautomation,refertotherelevant

instruction manuals.

2.4 - Electrical connections

IMPORTANT!

– All electrical connections must be made with the unit disconnected

from the mains power supply and with the buffer battery disconnected,

if present in the automation.

– Connections must be made exclusively by qualied personnel.

– Make sure that all the electric cables used are of a suitable type.

01. Loosen the screws of the cover.

02. Prepare the electrical cable routing holes.

03. Connect the cables as shown in the wiring diagram in g. 5.Toconnect

the electric power cable, see g. 6. Note – To facilitate cable connections,

the terminals can be removed from their seats.

• WiththeexceptionofthephotocellinputswhenthePHOTOTESTfunction

isactivated,iftheinputsoftheNC(NormallyClosed)contactsarenotinuse

theyshouldbejumpedwiththe“COMMON”terminal.Refertoparagraph

2.4.3 for further information.

• If there is more than one NC contact on the same input, they must be con-

nected in SERIES.

• IftheinputsoftheNO(NormallyOpen)contactsarenotusedtheyshouldbe

left free.

• IfthereismorethanoneNOcontactonthesameinput,theymustbecon-

nected in PARALLEL.

• Thecontactsmustbeelectromechanicalandpotential-free.Stageconnec-

tions,suchasthosedenedas“PNP”,“NPN”,“OpenCollector”,etc.arenot

allowed.

• If the leafs overlap, use jumper E (Fig. 6)toselectwhichmotorstartsuprst

during opening.

Key to gs. 2 - 5a - 5b - 5c:

Terminals Function Description Type of cable

L - N -

Power supply line Mains power supply 3x1,5mm

1÷3 Motor1 M1motorconnection 3x1,5mm

1÷3 Motor 2 M2motorconnection(Note1) 3x1,5mm

4÷5 Flashing light

Connectionofashinglight24V

max25W

2x1mm

6÷7 Open Gate indicator /

Elect.Lock

ConnectionforOpenGateIndicator24V

max5WorElectriclock12V

max

25VA(“Seechapter5-Programing”)

SCA:2x0,5mm

Electriclock:2x1mm

Common24V

(with

Everythinginstandby/

phototest)

PowerSupply+24V forTXphotocellswithphototest(max.100mA);“COM-

MON”forallinputs,safety,with“Everythinginstandby”functionactivated(Note2)

1x0,5mm

0V

Powersupply0V for services

1x0,5mm

24V

Powerinputforservices,without“Everythinginstandby”(24V

max200mA)

1x0,5mm

Common24V Commonforallinputs(+24V )without“Everythinginstandby”

1x0,5mm

12 STOP InputwithSTOPfunction(emergency,safetyshutdown)(Note3) 1x0,5mm

13 PHOTO NCInputforsafetydevices(photocells,sensitiveedges) 1x0,5mm

14 PHOTO1 NCInputforsafetydevices(photocells,sensitiveedges) 1x0,5mm

15 STEPBYSTEP Inputforcyclicalfunctioning(OPEN-STOP-CLOSE-STOP) 1x0,5mm

16 AUX Auxiliaryinput(Note4) 1x0,5mm

17÷18 Aerial Connection for the radio receiver aerial screenedcabletypeRG58

Note 1 – This is not used for single leaf gates (the control unit automatically recognises if only one motor has been installed).

Note 2 – The “Everything in stand by” function serves to reduce consumptions. For further details on the electrical connections refer to paragraph 2.4.1 ““Every-

thing in stand by/Phototest connection” and for programming refer to chapter 5.2.3 “Everything in stand by/Phototest function”.

Note 3 – The STOP input can be used for “NC” or constant resistance 8.2 kΩ contacts (please refer to the “Programming” chapter)

Note 4 – The AUX factory auxiliary input is programmed with the “Partial open type 1” function but can be programmed with any of the following functions:

Function Input type Description

PARTIALOPENTYPE1 NO Fully opens the upper leaf

PARTIALOPENTYPE2 NO Opensthetwoleafhalfway

OPEN NO Onlycarriesouttheopeningmanoeuvre
