Nice Robus RBS400 - Level 1 Programming (ON-OFF); Level 1 Programming Procedure

32 – ENGLISH
8.2 LEVEL 1 PROGRAMMING (ON-OFF)
All Level 1 functions are factory-set to “OFF” and can be modied at any time. To check the various functions, refer to “Table 18”.
8.2.1 LEVEL 1 PROGRAMMING PROCEDURE
m
The user has maximum 20 seconds to press the buttons consecutively during the programming procedure. After this time,
the procedure terminates automatically and memorises the changes made up to that time.
To perform Level 1 programming:
1. press and hold the
g
button until LED “L1” starts ashing
2. release the
g
button
3. press the
f
or
h
button to move the ashing LED to the LED associated with the function to be modied
4. press and release the
g
button immediately to change the status of the function:
– short ash = OFF
– long ash = ON
5. wait 20 seconds (maximum time), without pressing any button, to exit the programming mode.
l
To set other functions to “ON” or “OFF”, while the procedure is running, repeat points 2 and 3 during the phase itself.
Table 18
LEVEL 1 FUNCTIONS (ON-OFF)
LED Function Description
L1 Automatic closing
This function causes the gate to close automatically after the programmed pause time has elapsed. The factory-set Pause
Time is 30 seconds, but can be modied to 5, 15, 30, 45, 60, 80, 120 or 180 seconds. If the function has not been
activated, the “semi-automatic” mode applies.
L2 Close after photo
This function enables the gate to be kept open for the necessary transit time only. The “Photo” always causes an automatic
re-closing with a pause time of 5 seconds (regardless of the programmed value).
The automation always reaches the fully open position (even if Photo is disengaged beforehand). When Photo disengages,
automatic closing is triggered with a 5-second pause.
L3 Always Close
The “Always close” function will intervene, and the gate will close, if the open gate status is detected when the power
supply returns.
For safety reasons, the manoeuvre is preceded by 5 seconds of ashing.
If the function is disabled, the automation will remain stationary once the power is restored
L4 Stand-by
This function allows for minimising consumption and is particularly useful in cases when the back-up battery is used.
If this function is enabled, 1 minute after the completion of the manoeuvre the control unit turns off the transmitters of the
BlueBus photocells and all the LEDs, with the exception of the BlueBus LED, which instead ashes at a slower speed.
When a command arrives, the control unit resumes full operation.
If this function is inactive, there will be no reduction in the consumption.
L5 Peak
If this function is activated, the gradual acceleration at the beginning of each manoeuvre will be disengaged; it allows for
having surge force and is useful whenever static friction is high, e.g. if snow or ice are blocking the gate.
If the thrust is inactive, the manoeuvre will start with a gradual acceleration.
L6 Pre-ashing
With the pre-ashing function, a 3-second pause is added between the ashing light switch-on and the start of the
manoeuvre, in order to warn the user in advance of a potentially dangerous situation.
If pre-ashing is inactive, the asher will switch on when the manoeuvre starts.
L7
Deactivate internal
radio
Function ACTIVE: deactivates the BiDi radio inside the control unit.
Function NOT ACTIVE: normal operation.
Activate this function when using a type OXI external receiver.
L8 Slave mode
By activating this function, ROBUS becomes a “Slave”: this allows for synchronising 2 motors on opposing leaves on which
one motor functions as Master and the other as Slave; for further information, refer to the paragraph ““Slave” mode”.
l
During normal operation, in other words when no manoeuvre is under way, LEDs “L1 ... L8“” are on or off depending on
the status of the respective function; for example, “L1” is lit when the “Automatic Closing” function is enabled. During the
manoeuvre, LEDs “L1 ... L8” ash to signal the force required to move the automation at that time. If “L1” ashes, the force
required is low and so forth, until LED “L8” ashes to signal the maximum force. There is no relation between the force level
indicated by the LEDs during the movement (which is an absolute value) and the level indicated by the LEDs during the force
(which is a relative value) programming phase. See “L5” in “Table 19”.
