14 – ENGLISH
a
IMPORTANT. The gearmotor is factory-congured for be-
ing installed on the right-and side. (“Figure 26")
26
a
It can be installed on the left by shifting the selector as
indicated (“Figure 27")
27
3.7 MANUALLY UNLOCKING AND LOCKING THE
GEARMOTOR
The gearmotor is equipped with a mechanical unlocking system that al-
lows for opening and closing the gate manually.
These manual operations should only be performed in case of a power
outage, malfunctions or during the installation phases.
To unlock the device:
1. Open the locking hook (A) using the key provided (“Figure 28")
A
28
2. At this point, the automation can be moved manually to the desired
position.
To lock the gate, close the locking hook, turn the key anti-clockwise and
remove it.
29
