ENGLISH – 13
14. manually close the gate leaf leaving it 2/3 cm from the mechanical
stop and repeat the operations described above to fasten the limit
switch bracket (“Figure 21")
2-3 cm
21
22
15. if the anchor bolts were also used for fastening, cut away the ex-
cess part (“Figure 23")
23
16. secure the cable in the relevant cable clamp to avoid damaging it
during the successive phases (“Figure 24")
24
17. position the cover (N), fasten it with the screws provided, lock it
manually and remove the key supplied. (“Figure 25")
N
25
