Nice Robus RBS400 - Technical Specifications

54 – ENGLISH
TECHNICAL SPECIFICATIONS
11
11 TECHNICAL SPECIFICATIONS
l
All technical specications stated in this section refer to an ambient temperature of 20°C (± 5°C). Nice S.p.A. reserves the
right to apply modications to the product at any time when deemed necessary, without altering its functions and intended
use.
Table 33
GEARMOTOR TECHNICAL SPECIFICATIONS
Description
RB400
RB400/V1
RB400/AU01
RB600
RB600/V1
RB600/AU01
RB600HS
RB600HS/V1
RB600HS/AU01
Product type
Electro-mechanical gearmotor for the automatic movement of sliding gates for residential use, inclusive of electronic control
unit
Pinion Z15m4 Z15m4 Z15m4
Maximum frequency of
operating cycles
(at nominal torque)
80 cycles per day (the control unit limits
the cycles to the maximum specied in
“Table 3”.
100 cycles per day (the control unit
limits the cycles to the maximum
specied in “Table 3”.
100 cycles per day (the control unit
limits the cycles to the maximum
specied in “Table 3”.
Maximum continuous
operating time
(at nominal torque)
7 minutes (the control unit limits
continuous operation to the maximum
specied in “Table 3”.
7 minutes (the control unit limits
continuous operation to the maximum
specied in “Table 3”.
6 minutes (the control unit limits
continuous operation to the maximum
specied in “Table 3”.
Operating limits ROBUS is generally able to automate gates up to the weight or length limits specied in “Table 1”.
Durability Estimated between 20,000 and 250,000 cycles, depending on the conditions shown in “Table 3”.
Power supply (230V) 230V~ (+10% -15%) 50/60Hz 230V~ (+10% -15%) 50/60Hz 230V~ (+10% -15%) 50/60Hz
Version V1 (120V) 120V~ 50/60Hz 120V~ 50/60Hz 120V~ 50/60Hz
Version AU01 (250 V) 250 V~ 50/60Hz 250V~ 50/60Hz 250 V~ 50/60Hz
Maximum absorbed power
at peak
[corresponding to amperes]
330W [2A]
[3.9 A version /V1]
[3.9A version /AU01]
500W [2,5A]
[3.9 A version /V1]
[3.9A version /AU01]
500W [2,5A]
[3.9 A version /V1]
[3.9A version /AU01]
Insulation class 1 (a safety earthing system is required)
Emergency power supply With PS124 optional accessory
Warning light output [Note
1]
For 2 ELDC LED warning lights or maximum 2 x 12 V 21 W lamps
OGI output [Note 1] For one 24 V maximum 10 W lamp (the output voltage may vary between –30 and +50% and can also control small relays)
BLUEBUS output One output with maximum load of 15 BLUEBUS units
STOP input
For normally closed or normally open contacts or for a 8.2 kΩ xed resistor; in self-recognition mode (any variation from the
memorised status triggers the “STOP” command)
Sbs input For normally open contacts (closing of the contact triggers the Step-by-Step command)
PHOTO input Input for relay photocells
CLOSE input Present on the expansion board (accessory). Refer to the “I/O expansion board (optional accessory)” paragraph.
AUX_IN input Present on the expansion board (accessory). Refer to the “I/O expansion board (optional accessory)” paragraph.
Radio connector SM connector for SMXI or OXI receivers
Radio ANTENNA input 52 Ω for RG58 or similar type cable
Programmable functions
8 ON-OFF and 8 adjustable functions. Refer to the “Level 1 programming (ON-OFF)” and “Level 2 programming
(adjustable parameters)” paragraphs.
Self-learning functions
Automatic recognition of devices connected to the BlueBus output
Self-recognition of the type of “STOP” device (Normally Open, Normally Closed contact or 8.2 kΩ resistor)
Self-learning of the gate length and calculation of the slowdown and partial opening points
Note 1 The output can be programmed with other functions (see “Table 19” on page 33 34) or through compatible interfaces.
