3.3 PRODUCT IDENTIFICATION AND OVERALL
DIMENSIONS
The overall dimensions of the product are shown in “Figure 2”.
340 mm 220 mm
303 mm
85 mm
2
3.4 RECEIPT OF THE PRODUCT
All the components contained in the kit are illustrated and listed below.
E
D
B
C
A
Mod. 600 HS
Mod. 400 / 600
3
A Gearmotor
B Metal hardware (screws, washers, etc.)
C Anchor bolts
D Foundation plate
E Accessory box
