ENGLISH – 39
9.2 REPLACING THE MOTOR CONTROL CARD
In case of a malfunction, the motor control card can be replaced by per-
forming the procedures described below
1. Disconnect the power supply to the control unit by removing the
fuse F2 and, if necessary, the emergency power supply
2. Remove any cables
3. Remove the control unit (refer to “Removing the control unit” for
relevant information)
4. Press the plastic cover (A) in the indicated points and remove it
A
57
1. Hold the card with one hand
2. Shift the plastic stop (B) towards the left
3. Remove the card and replace it with a conforming version
58
