42 – ENGLISH
Table 28
LEDS ON THE CONTROL UNIT BUTTONS
LED 1 Description
OFF During normal operation, this indicates that “Automatic Closing” is disabled.
On During normal operation, this indicates that “Automatic Closing” is active.
Flashes
Function programming in progress.
If it ashes together with “L2”, it means that the device learning phase must be carried out (refer to the “Device learning”
paragraph).
LED 2 Description
OFF During normal operation, it signals that the “Close after photo” mode is not active.
On During normal operation, it signals that the “Close after photo” mode is active.
Flashes
Function programming in progress.
If it ashes together with “L1”, it means that the device learning phase must be carried out (see the “Device learning” paragraph)
LED 3 Description
OFF During normal operation, this indicates that “Always Close” is not active.
On During normal operation, it signals that “Always close” is active.
Flashes
Function programming in progress.
If it ashes together with L4, it means that the leaf opening and closing positions must be learned (refer to the “Leaf length
learning” paragraph).
LED 4 Description
OFF During normal operation, it signals that the “Stand-by” mode is not active.
On During normal operation, it signals that the “Stand-by” mode is active.
Flashes
Function programming in progress.
If it ashes together with L3, it means that the leaf opening and closing positions must be learned (refer to the “Leaf length
learning” paragraph).
LED 5 Description
OFF During normal operation, it indicates that the “Peak” mode is not active.
On During normal operation, it signals that the “Peak” mode is active.
Flashes Function programming in progress.
LED 6 Description
OFF During normal operation, it signals that the “Pre-ashing” mode is not active.
On During normal operation, it signals that the “Pre-ashing” mode is active.
Flashes Function programming in progress.
LED 7 Description
OFF During normal operation, it indicates that “Internal radio inhibition” is not enabled.
On During normal operation, it indicates that “Internal radio inhibition” is enabled.
Flashes Function programming in progress.
LED 8 Description
OFF During normal operation, it signals that ROBUS is congured as master.
On During normal operation, it signals that ROBUS is congured as slave.
Flashes Function programming in progress.
a
If the conguration of a parameter (Level 2) is not recognised with respect to the congurations present, the control unit
will switch on the two LEDs L1 and L8 simultaneously and intermittently to signal that the present value is out of range. If
necessary, the values can be forced by pressing the
f
or
h
button.
a
Warning! During each manoeuvre, the LEDs light up to signal the force applied by the motor to move the automation.
During each manoeuvre, the LEDs light up proportionally to signal the force applied by the motor to move the automation. Below is the sequence with
which the LEDs light up in relation to the force:
– from L1 to L3 in case of low force
– from L1 to L5 in case of medium force
– from L1 to L8 in case of high force.
a
WARNING: with the motor stationary, the sequential lighting up of LEDs L1
4
L2
4
L3
4
L4
4
L5
4
L6
4
L7
4
L8 indicates that
the product’s FW is being updated, so it is necessary to wait for the updating process to end before the automation can be
used again! We suggest not disconnecting the motor from the power supply.
