Chassis labels
The SuperK SELECT chassis includes multiple labels that indicate hazards and
safety and product information. The labels are located on the panels as
described in Table 3 with the panels shown in Figure 11 and Figure 12.
Table 3 Chassis labels
Figure 11 Side panel manufacturing label
Label Panel Description
Class 4 Laser
Warning
Top Safety information indicating the laser
emission radiation class and
precautions to take when the laser is
operating.
Laser Aperture Top Safety information alert indicating the
location of the aperture where laser
radiation is emitted from the device.
Manufacturing Side Manufacturing information including
address, part and serial number, date
manufactured and regulatory
compliance.
Laser
Radiation
Warning
Top Safety information alert indicating this
area of the device is near a source of
dangerous laser emissions.
