NKT Photonics SUPERK SELECT User Manual

57
A Specifications
Table 4 Optical
Table 5 Interfaces
Table 6 Mechanical dimensions
Table 7 Electrical specifications – External RF Drivers
Parameter
Number of tunable lines
1 – 8 (per AOTF)
Filter bandwidth of AOTF (UV-VIS) 1) [nm]
i
i. Collimated free-space output, FWHM bandwidth.
1.8 – 8.5
Filter bandwidth of AOTF (VIS1x/VIS4x) 1) [nm]
i
0.5 – 1.85 / 2.5 – 8.5
Filter bandwidth of AOTF (VIS-nIR) 1) [nm]
i
3.5 – 14
Filter bandwidth of AOTF (nIR1/nIR2) 1) [nm]
i
1.8 – 5 / 2.6 – 9.6
Filter bandwidth of AOTF (IR) 1) [nm]
i
6.4 – 19.8
AOTF deflection efficiency [%]
> 90 (1 – 8 channel operation)
Polarization
ii
ii. Horizontal with respect to base.
Linear
Output mode
Fiber or free-space collimated
Mechanical shutter
Integrated for both ports
Laser safety interlock Integrated
All Chassis Models
External bus
DB-15 Female
Monitor BNC (Optional - Custom feature, contact NKT Photonics)
Specification Select Module External RF Driver
Size (H x W x D)
68 x 272 x 212 mm 66 x 441 x 370 mm
Weight 7.9 kg 5.0 kg
Specification
Supply voltage
100 to 240 VAC
Power dissipation
60 W maximum
Fuse T2A/250V
