5.3 Provisioning Service Entities
The nodes in a VC are represented as the cards of a chassis. Each card is assigned
a slot number. Using the slot number, services are provisioned on the card using the
format slot-number/mda-number/port-number:sap-id, where the slot-number is
configured for every node/card, the mda-number is always set to 1 for all
7210 SAS-Sx/S 1/10GE platforms supporting VC, and the port-number corresponds
to the front-panel Ethernet port number and ranges from 1 to 28 or from 1 to 52 for
7210 SAS-Sx/S 1/10GE platforms.
5.4 Preprovisioning a VC
To preprovision a VC, users must configure the card-type for the slot they want to
preprovision. When the card type is configured, the ports are automatically created
for that slot, allowing configuration of the services using the ports of the slot.
The vc-stack-node command can be configured later and is independent of the
card-type configuration. The vc-stack-node configuration identifies the slot and the
MAC address of the node and is used only by the IMM-only node to become part of
the VC. If the software detects a mismatch between the hardware type of the IMM-
only node and the configured/provisioned card type, it logs an error and reboots the
card, allowing the user to correct the value and fix the problem.
sas-s-48sfp-4sfpp 7210 SAS-S 1/10GE 48F 4SFP+
sas-s-24t-4sfpp 7210 SAS-S 1/10GE 24T 4SFP+
sas-s-48t-4sfpp 7210 SAS-S 1/10GE 48T 4SFP+
sas-s-24tp-4sfpp 7210 SAS-S 1/10GE 24Tp 4SFP+ PoE
sas-s-48tp-4sfpp 7210 SAS-S 1/10GE 48Tp 4SFP+ PoE
Table 27 Card Types for 7210 SAS-S 1/10GE Platform (Continued)
Card Type 7210 SAS-S 1/10GE Platform
