Virtual Chassis

236

7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System

Configuration Guide

Use subject to Terms available at: www.nokia.com

3HE 17358 AAAB TQZZA

Mac and IPv4 Resource : 2 Mac-only Resource : disable

IPv6 128 bit Resource : disable Mac and IPv6 64 bit Resour*: disable

-------------------------------------------------------------------------------

Egr sap agg-meter : disable

-------------------------------------------------------------------------------

MBS pool : Node

-------------------------------------------------------------------------------

Decommissioned Ports : Not Applicable

-------------------------------------------------------------------------------

===============================================================================

* indicates that the corresponding row element may have been truncated.

# indicates that the value will take effect only after reboot or clear card.

5.6 VC Boot Scenarios

This section describes the required configurations and the expected behaviors of

different boot up scenarios.

5.6.1 First Time Manual Boot of Nodes in the Stack

The following steps outline how to manually bring up a VC using nodes shipped from

the factory that are being booted up for the first time.

Users can boot up a single node or a set of nodes that are to be part of a VC. As well,

users can power up one node, all the nodes, or a set of nodes; there is no restriction

on the power sequence. The following steps describe the sequence when all nodes

are booted up together; however, the steps here do not dictate the order of service

provisioning and do not preclude preprovisioning of services on the active CPM.

Service preprovisioning is allowed after the VC configuration, including the VC node

member configuration, is complete.

Step 1. Identify the two nodes that will take on the CPM role.

Step 2. Ensure there is console access to each CPM node to drive the boot

process. See the following for information: 7210 SAS-Sx 10/100GE

Console Port, 7210 SAS-S 1/10GE Console Port, and Procedure to

Connect to a Console.

Step 3. Ensure the CPM nodes are powered on.

Note: The CPM-IMM nodes are configured through the BOF and do not require further

configuration to be part of the VC.
