System Management
362
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
© 2021 Nokia.
Use subject to Terms available at: www.nokia.com
3HE 17358 AAAB TQZZA
6.11.6.2 System Alarm Contact Inputs
7210 SAS hardware supports alarm contact inputs that allow the operator to monitor
and report changes in external environmental conditions. In a remote or outdoor
deployment, alarm contact inputs allow the operator to detect conditions, for
example, air conditioner fault, open door.
You can configure generation of events when alarm contact inputs transition
between the open and close states. For each generated event, you can specify the
following:
• action associated with each state transition
• severity associated with each state transition
• log message associated with each state transition
6.11.7 Configuring 1830 VWM
The following is a sample output for the creation of a vwm-shelf.
*A:NS1333C2676# configure system vwm-shelf 3 vwm-type ec-cw create
*A:NS1333C2676>configure>system>vwm-shelf$ info
----------------------------------------------
no shutdown
----------------------------------------------
*A:NS1333C2676>configure>system>vwm-shelf$ info detail
----------------------------------------------
card 1
shutdown
no card-type
exit
card 2
shutdown
no card-type
exit
no shutdown
*A:NS1333C2676>configure>system>vwm-shelf$
*A:7210 SAS>show system vwm-shelf 7
===========================================================================
Shelf Summary
Note: Card 1 corresponds to slot #1 and card 2 corresponds to slot #2 on the 1830 CWDM
device. The optical modules or line cards are inserted into these slots.
