7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
3HE 17358 AAAB TQZZA © 2021 Nokia.
Use subject to Terms available at: www.nokia.com
263
• To force a switchover from an active CPM to a standby, use the admin
redundancy force-switchover command. You can also use the config system
switchover-exec and admin redundancy force-switchover now CLI
commands to configure a batch file that runs after a failover.
6.3 Temperature Threshold Alarm and Fan Speed
Table 29 lists the over-temperature thresholds for 7210 SAS devices.
The 7210 SAS system software controls the fans by monitoring the internal
temperature of the chassis. The software manages the fan speed to maintain the
internal temperature within operational limits.
The 7210 SAS-R6 supports overheat protection reboot. This feature protects the
IMM and CPM cards when the temperature exceeds system-defined temperature
thresholds; these thresholds are not user-configurable. The software monitors the
temperature of each card and if the temperature exceeds the threshold, the system
raises an over-temperature critical event. The system reboots all overheated CPM
Table 29 Over-Temperature Threshold for 7210 SAS Devices
Device Variants Minimum Temperature
(in degrees centigrade)
Maximum Temperature
(in degrees centigrade)
7210 SAS-M 0 58
7210 SAS-M 24F 2XFP ETR -21 68
7210 SAS-T 0 58
7210 SAS-T ETR -21 68
7210 SAS-R6 -1 74
7210 SAS-R12 0 96
7210 SAS-Mxp 0 76
7210 SAS-Mxp ETR -10 80
7210 SAS-Sx/S 1/10GE and
7210 SAS-Sx 10/100GE
085
