Description This command allocates maximum resources for use by egress filter policies using IPv4
criteria or MAC criteria. The resources allocated are allocated on a first-come-first-serve
basis among service entities (for example, SAP and IP interface) using IPv4 and MAC criteria
egress filter policies.
The resources cannot be shared with any other egress filter policies that specify other match
criteria. Refer to the 7210 SAS-M, T, R6, R12, Mxp, Sx, S Router Configuration Guide for
more information on resource allocation and fields available for use.
The no form of this command specifies that the software does not allocate any resources for
use by egress filter policies using MAC or IPv4 criteria. If no resources are allocated for use,
the software fails all attempts to associate a service entity (for example, SAP and IP interface)
with a filter policy using this match criteria.
Default mac-ipv4-match-enable 2 (to maintain backward compatibility with earlier releases)
Parameters num-resources — Specifies the maximum amount of resources for use by this filter
match criteria. A minimum value of 2 (indicating two chunks of resources) must be
allocated to use this match-criteria. If not, association of a policy with mac and ipv4
criteria to a SAP will fail. It is mutually exclusive to use of SAP egress aggregate
meter.
Values Table 46 lists the parameter values.
Table 46 Number of Resources Available for MAC-IPv4-Match-Enable
Platforms Min value
(per node)
Max value
(per node)
Default
Values
7210 SAS-M (per node) 0 2 0
7210 SAS-T access-uplink mode (per node) 0 2 0
7210 SAS-T network mode (per node) 0 2 0
7210 SAS-S 1/10GE (per node) (standalone) 0 2 0
7210 SAS-Sx 1/10GE standalone-VC) 0 2 2
7210 SAS-S 1/10GE (per node) (standalone) 0 2 0
7210 SAS-S 1/10GE (standalone-VC) 0 2 2
7210 SAS-Sx 10/100GE (per node) 0 2 2
7210 SAS-R6 and 7210 SAS-R12 IMM-c (per
node)
022
7210 SAS-Mxp 0 2 0
7210 SAS-R6 IMMv1 and IMMv2 0 2 0
7210 SAS-R12 IMMv2 0 2 0
