7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
3HE 17358 AAAB TQZZA © 2021 Nokia.
Use subject to Terms available at: www.nokia.com
629
statistics
Syntax statistics
Context show>system>ptp
Platforms 7210 SAS-M (network and access-uplink), 7210 SAS-Mxp, 7210 SAS-R6, 7210 SAS-R12,
7210 SAS-Sx 10/100GE, 7210 SAS-T (network and access-uplink)
Table 78 Output Fields: PTP Port
Label Description
Port Summary
Port Displays the port numbers
PTP Adm/Opr Displays the admin and oper state
PTP State Displays the PTP state for each port: initializing, listening,
uncalibrated, slave, master, or passive
Tx Rate Displays the Tx rate for each port
Rx Rate Displays the Rx rate for each port
Port Information
Port Displays the PTP port number
PTP Admin State Displays the PTP administrative state of the port
PTP Oper State Displays the PTP operational state of the port
Local MAC Addr Displays the local MAC address of the port
Multicast MAC Addr Displays the multicast MAC address of the port
Cfg Sync Rate Displays the configured sync packet rate
Cfg Delay Req Rate Displays the configure delay request packet rate
Master-Only Displays the master-only command value: true or false
G.8275.1 Priority Displays the configured priority value
PTP Port Number Displays the internal port number associated with this port
PTP Port State Displays the PTP port state: disabled, listening, slave, master,
passive, or faulty
Neighbors Displays the number of neighbors
Timestamp Point Displays the point at which time-stamping is done
