1 General
BU 0250 en-3021 25
Pos: 48 /Anleitungen/ Elektronik/FU und St arter/1. Allgemeines/ Typenschlüssel/ Typenschlüssel Fel dverteiler_01 [SK 2xxE -FDS] @ 11\mod_1463056952598_3 88.docx @ 320613 @ 3 @ 1
1.7.2 Field distribution type codes
SK 250E-FDS-301-340-A (-xxx)
Configuration features (multiple statements possible)
Radio interference filter: O = Without, A = Class A1(C2)
Mains voltage: x40 = 400 V
Number of mains phases: 3xx = 3-phase
Digits before decimal point for power: 0 = 0.xx, 1 = 0x.x0
Rated power of the FI: 370 = 0.37 kW, … 301 = 3.0 kW, ...
751 = 7.50 kW
Frequency
inverter series:
SK 250E-FDS, SK 260E-FDS, SK 270E-FDS,
SK 280E-FDS
Pos: 49 /Anleitungen/ Elektronik/FU und St arter/1. Allgemeines/ Typenschlüssel/ Typenschlüssel Fel dverteiler_02 (Ausst attungskennzeic hen_0) [SK xxxE-FDS] @ 11\mod_14 64617559852_388.d ocx @ 325080 @ 5 @ 1
Configuration code
Pos: 50 /Anleitungen/ Elektronik/FU und St arter/1. Allgemeines/ Typenschlüssel/ Typenschlüssel Fel dverteiler_02 (Ausst attungskennzeic hen_1) [SK 2xxE-FDS] @ 50\mod_16 00849961764_388.d ocx @ 2672080 @ @ 1
Meaning
-AS-i
Actuator-sensor interface with “AS-i” connector option
-ASS
Actuator-sensor interface with “ASS” connector option
-AUX
Actuator-sensor interface with “AUX” connector option
-AXS
Actuator-sensor interface with “AXS” connector option
-BRI
Integrated braking resistor
-BWRN
Integrated brake rectifier for controlling a 205 V DC brake
-EEP
Plug-in EEPROM for additional data backup
-FANO
1)
Heat sink with attached fan (only for devices < 2.2 kW)
-HWR
Integrated brake rectifier for controlling a 180 V DC brake
-HVS
Integrated 24 V power supply
-TISTO
Internal STO input The digital output of an integrated fail-safe module (e.g. SK CU4-PNS) is
connected to this input in order to trigger the function “Safe Torque Switch-off” (STO).
-TIDIO
With the aid of the -TIDIO option, the digital IOs of the frequency inverter are connected to the
corresponding IOs of an SK CU4- installed in the FI.
-TIMSW
If the frequency inverter is equipped with a maintenance switch, the auxiliary contact of the
maintenance switch (if present) can be integrated into the frequency inverter and evaluated
(maintenance switch “Switch setting ON / OFF).
-USB
RS232/RS485 interface: USB port in place of the RJ12 port.
Note: Parameter boxes cannot be connected to the USB port. In this case parameterisation and
diagnosis is only possible via a PC with NORDCON software.
1)
As standard, frequency inverters with powers > 1.5 kW are equipped with an attached fan. The equipment code (-FANO) is then not
explicitly stated in the type code.
