7 Menu Operations
www.novastar.tech
15
7 Menu Operations
The MCTRL660 PRO is powerful and easy to use. You can quickly configure the LED
screen to light it up and display the entire input source following steps in 7.1 Quick
Screen Configuration. With other menu settings, you can further improve the LED
screen display effect.
Instruction on knob operations:

Press the knob to enter a menu page or confirm an operation.

Rotate the knob to select a menu item or adjust a menu parameter.

Hold down the knob and BACK button simultaneously for 3 seconds to lock or
unlock all the buttons.
Quick Screen Configuration
Following the steps below, namely Setting Input Source > Setting Input Resolution >
Setting Color Depth > Quickly Configuring Screen, you can quickly light up the LED
screen to display the entire input source.
7.1.1 Step 1 Setting Input Source
Supported input sources include 3G-SDI, Single-Link DVI and HDMI 1.4a. Select an
input source that matches the type of the inputted external video source.
Constraints on input sources:

Only one video input source can be selected at the same time.

Interlaced SDI video sources do not support low latency.

SDI video sources do not support the following functions:
− Color depth adjustment
− Preset resolution
− Custom resolution
− Image mirroring
