NovaStar MCTRL660 PRO - 7.7 Backup and Restore; 7.8 Advanced Settings

MCTRL660 PRO Independent Controller
User Manual
7 Menu Operations
www.novastar.tech
24
Figure 7-18 Top-bottom mirroring of the entire image
As shown above, after you set the mirroring mode as top-bottom for Ethernet ports 1-
4, the entire image is mirrored vertically.
Backup and Restore
Figure 7-19 Backup and restore

Back up the system configuration to the controller.

Restore the system configuration from the controller.

Restore the receiving card configuration from the controller.

Restore the sending card configuration from the controller.
System configuration includes configuration files of the sending card (namely the
controller) and receiving cards.
Advanced Settings
Figure 7-20 Advanced settings
