NovaStar MCTRL660 PRO - Features of MCTRL660 PRO; 2.1 Features; 2.2 Video Source Features

MCTRL660 PRO Independent Controller
User Manual
2 Features
www.novastar.tech
2
2 Features
Features

Input of ultra-high color depths: 10-bit/12-bit RGB 4:4:4/YCbCr 4:4:4, with input
resolutions up to 1920×1080@60Hz

Low latency: Less than 1 ms (when the start position of image is 0.)

Auto LED screen configuration

Web control

Image mirroring

Dual working modes: working as sending card and fiber converter

Pixel level brightness and chroma calibration

Supports individual Gamma adjustment for RGB when the color depth of input
source is 10-bit or 12-bit.

Monitoring of inputs

One-click backup and recovery

Multiple MCTRL660 PRO units can be cascaded.
Video Source Features
Input Connector
Features
Color Depth
Sampling Format
Maximum Input Resolution
HDMI 1.4a
8-bit
RGB 4:4:4
YCbCr 4:4:4
YCbCr 4:2:2
YCbCr 4:2:0
1920×1200@60Hz
10-bit/12-bit
1920×1080@60Hz
Single-link DVI
8-bit
1920×1200@60Hz
10-bit/12-bit
1920×1080@60Hz
3G-SDI
Maximum supported input resolution: 1920×1080@60Hz.
Note:

3G-SDI input sources do not support input resolution and color depth settings.
XI'AN NOVASTAR TECH CO., LTD.
