4 Cascading Devices

The control computer needs to control multiple MCTRL660 PRO devices.
Cascade devices via USB IN and USB OUT ports of the MCTRL660 PRO
devices. Up to 8 devices can be cascaded.

Multiple MCTRL660 PRO devices need to output image simultaneously.
Cascade devices via GENLOCK IN and GENLOCK LOOP connectors of the
MCTRL660 PRO devices. Up to 8 devices can be cascaded.
