5.5 Output Settings (Offline)
This section configures the timing signals that will be generated for the outputs of the clock. The length of
the section depends on the number of outputs. The same settings can be made in the webpage as
described in Output Settings (Online).
Note that the POLARITY can only be set in the configuration file and not in the webpage.
See Appendix A – Options List for information about how to interpret the part number and determine the
number and type of outputs available in your unit.
# Signal generation on OUTPUT1 .. OUTPUT6
[OUTPUT1]
# OPTIONS = OFF, IRIG-B000, IRIG-B002, IRIG-B004, IRIG-B006, PPS, PPM
SIGNAL = IRIG-B004
TIME = LOCAL
POLARITY = NORMAL
[OUTPUT2]
# OPTIONS = OFF, IRIG-B120, IRIG-B122, IRIG-B124, IRIG-B126
SIGNAL = IRIG-B124
TIME = LOCAL
POLARITY = NORMAL
Parameter
Description
[OUTPUTn]
Outputs are defined in section [OUTPUTn].
SIGNAL
Configures the type of signal that will be generated on OUTPUTn. Valid
values are:
Card Name
Card Type
Signals
-1
-2
-F
Single unmodulated output
Dual unmodulated outputs
Dual fiber outputs
OFF
PPM
PPS
IRIG-B000
IRIG-B002
IRIG-B004
IRIG-B006
-A
Dual modulated outputs
OFF
IRIG-B120
IRIG-B122
IRIG-B124
IRIG-B126
Default: OFF
