Novatech Kronos 2 Series - Table 35: Clock Specifications

Kronos Series 3
58
Component
Specification
Ethernet ports
▪ 1 ea RJ45 1Gbps for configuration
▪ 4 ea SFP slots with PRP support
▪ VLAN IEEE 802.1Q support
▪ PTPv2, IEEE 1588-2008v2
▪ Embedded NTP/SNTP server (protocol version 4)
▪ SNMP agent, with trap generation (versions v1, v2c and v3)
▪ Syslog
SFP Transceivers
Model
Mode
Connector
Distance
Wavelength
Speed
MM1
Multimode
LC
550m
850nm
1Gbps
SM1
Single mode
LC
10km
1310nm
1Gbps
SM4
Single mode
LC
40km
1310nm
1Gbps
RJ1
Copper
RJ45
100m
1Gbps
Supported PTP
profiles
▪ Default - UDP
▪ Default - 802.3
▪ IEEE C37.238-2011
▪ IEEE C37.238-2017
▪ IEC 61850-9-3:2016
Power supply
▪ Voltage: 18-72V dc or 80-300V dc / 85-264V ac (50/60Hz)
▪ Power consumption: 30VA max
▪ Redundant power supply options
Alarm dry contact
▪ Form C
▪ Breaking capacity: 300mA @ 300V dc (resistive load)
Environment
▪ Rated for operation from -40°C to +70°C
▪ 5 to 95%, non-condensing relative humidity
▪ IP40-rated enclosure protection
Dimensions and
weight
▪ Width x depth: 19” x 6.1”
▪ Front panel height: 1RU
Table 35: Clock specifications
