Novatech Kronos 2 Series - Table 24: Enable PTP by Port; Table 25: PTP Parameters and Value Ranges

Kronos Series 3
44
DELAYINTERVAL_B = 1
GRANDMASTERID_B = 200
VLANENABLE_B = TRUE
VLANID_B = 0
VLANPRIORITY_B = 4
Parameter
Description
ENABLE_B
TRUE enables PTP on the respective port.
FALSE disables PTP on the respective port.
Table 24: Enable PTP by port
The following table shows the default value for each parameter. If a range in shown in parentheses, then
the profile allows setting the value for this parameter in that range.
Parameter
Default
(UDP)
Default
(802.3)
IEEE
C37.238-
2011
IEEE
C37.238-
2017
IEC 61850-
9-3:2016
LAYER_B
UDP
L2
L2
L2
L2
DOMAIN_B
0
(0..127)
0
(0..127)
0
(0..127)
254 (or
0..127)
93
(0..255)
PRIORITY1_B
128
(0..255)
128
(0..255)
128
128
(0..255)
128
(0..255)
PRIORITY2_B
128
(0..255)
128
(0..255)
128
128
(0..255)
128
(0..255)
PATHDELAYMECHANISM_B
P2P (or
E2E)
P2P (or
E2E)
P2P
P2P
P2P
ANNOUNCEINTERVAL_B
1 (or 2,
4, 8, 16)
1 (or 2,
4, 8, 16)
1
1
1
ANNOUNCETIMEOUT_B
2 (2..10)
2 (2..10)
2
3
3
SYNCINTERVAL_B
1 (or
0.5, 2)
1 (or
0.5, 2)
1
1
1
DELAYINTERVAL_B
1 (or 2,
4, 8, 16,
32)
1 (or 2,
4, 8, 16,
32)
1
1
1
GRANDMASTERID_B
0
0
5
(3..254)
5
(0..65535)
0
VLANENABLE_B
FALSE
FALSE
FALSE
(TRUE)
FALSE
(TRUE)
FALSE
(TRUE)
VLANID_B
0
(0..4094)
0
(0..4094)
0
(0..4094)
VLANPRIORITY_B
4 (0..7)
4 (0..7)
4 (0..7)
Table 25: PTP parameters and value ranges
