Apr. 25, 2022 Page 41 of 57 Rev 1.02.019

ECLIPSE USER MANUAL

Configuration of Cortex-A, Multi-core SMP and AMP system

4.10.1 Preliminary Preparation

Suggest using Nu-Link2 family as debugger, and being sure to upgrade Nu-Link2 firmware version

higher than v3.09.7380r.

The term SMP stands for symmetric mulitiprocessing, AMP is asymmetric mulitiprocessing.

Nu-Link2 had built-in CMSIS-DAP interface from v3.09.7380r, and this CMSIS-DAP interface is used to

support Single Cortex-A, Multi-Core SMP and AMP (Cortex-A + Cortex-M).

Besides, NuEclipse provides GNU toolchain for the Cortex-A family which resides in NuEclipse/Others

folder. After configuring this toolchain (see Section 3.1.3), we can build MA35D1’s projects.
