LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 32 of 105
NXP Semiconductors
LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
generates an RTC wake-up interrupt request, which can wake up the part. During deep
power-down mode, the contents of the SRAM and registers are not retained. All functional
pins are tri-stated in deep power-down mode.
Table 8
shows the peripheral configuration in reduced power modes.
Table 9 shows the wake-up sources for reduced power modes.
Table 8. Peripheral configuration in reduced power modes
Peripheral Reduced power mode
Sleep Deep-sleep Deep power-down
FRO Software configured Software configured Off
Flash Software configured Standby Off
BOD Software configured Software configured Off
PLL Software configured Off Off
Watchdog osc and
WWDT
Software configured Software configured Off
Micro-tick Timer Software configured Software configured Off
DMA Active Configurable some for operations, see Section 7.13.2
Off
USART Software configured Off; but can create a wake-up interrupt in synchronous
slave mode or 32 kHz clock mode
Off
SPI Software configured Off; but can create a wake-up interrupt in slave mode Off
I2C Software configured Off; but can create a wake-up interrupt in slave mode Off
USB Software configured Software configured Off
DMIC Software configured Software configured Off
Other digital peripherals Software configured Off Off
RTC oscillator Software configured Software configured Software configured
Table 9. Wake-up sources for reduced power modes
Power mode Wake-up source Conditions
Sleep Any interrupt Enable interrupt in NVIC.
HWWAKE Certain Flexcomm Interface and DMIC subsystem activity.
