3.4 Overview of Parts and Features – Non-Draft Shield Models
Top View
Rear View
Bottom View
Side View
Figure 3-2. Explorer Base (models EX2202, EX4202, EX6202, EX10202, EX6201, EX10201)
Illuminated
Level
Indicator
Touchless
Sensors
Touchless
Sensors with
Indicator Li
g
hts
Type label
(M, N models only)
Data label
Terminal cable
storage clips
Lock switch
Weigh
Below
Access
Foot; Non-
Adjustable
Leveling
Thumbwheels
Power
Connection
