Open the memory cover.
(1) Release the lock by pushing the knob of the memory cover in the direction of arrow and open
the memory cover.
Install the memory.
Note! Do not touch electronic parts and connector terminal.
(1) Neutralize static electricity by letting the bag touch the metal part before taking out the memory
from the bag.
(2) Pay attention to the direction of the memory. There is a cut on the terminal part of the memory
to fit it into the connector of the slot.
(3) Insert the memory in the empty slot and bring it down to the circuit board side.
2
1
Memory Cover
Knob
