Oki MC873dn User Manual

45850101TH Rev.1
3-5
Oki Data CONFIDENTIAL
3. MAINTENANCE MENUS
Item1 Item2 Item3 Item4 Item5 Value
Default
value
ODA
Default
value
OEL
Default
value
JP
Notes
Password Scanner
Maintenance
Adjust Scan
Position
ADF
(Frontside)
Side Reg. +30~ -17 mm 0 0 0 Adjusting the position of the scanning start pixel by one Step=4/600
dpi (= 0.17mm) at the book scanning. This Item use the adjustment of
registration when ADF duplex scanning.
Front Edge +30 ~ -30 mm 0 0 0 When reading a document from the ADF, add a value for the basic
value when reading the shadow of the front edge of the document. To
skip the front edge of the document, add a negative value.
Increase or decrease the number of motor pulses from detection by
the sensor of the front edge of the media until actual reading starts.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
Back Edge +30 ~ -30 mm 0 0 0 When reading a document from the ADF, add a value for the basic
value when skipping the back edge of the document. To read the
shadow of the back edge of the document, add a negative value.
Increase or decrease the number of motor pulses from detection by
the sensor of the back edge of the media until actual reading ends.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
ADF
(Backside)
Side Reg. +30~ -17 mm 0 0 0 Adjusting the position of the scanning start pixel by one Step=4/600
dpi (= 0.17mm) at the book scanning.This Item use the adjustment of
registration when ADF duplex scanning.
Front Edge +30 ~ -30 mm 0 0 0 When reading a document from the ADF, add a value for the basic
value when reading the shadow of the front edge of the document. To
skip the front edge of the document, add a negative value.
Increase or decrease the number of motor pulses from detection by
the sensor of the front edge of the media until actual reading starts.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
Back Edg +30 ~ -30 mm 0 0 0 When reading a document from the ADF, add a value for the basic
value when skipping the back edge of the document. To read the
shadow of the back edge of the document, add a negative value.
Increase or decrease the number of motor pulses from detection by
the sensor of the back edge of the media until actual reading ends.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
Adjust
ADF Scan
Position
+30 ~ -30 mm 0 0 0 Set the CIS reading position of the ADF for the focusing standard.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm). This is
correlated to adjustment of the ADF front edge position.
Adjust Mech. Adjust FB
Motor
FB Drive
Current
10 ~ 1400 [mA] 530 [mA] 530 [mA] Only for engineering test Connect a panel or PC and set the electric
current value of the scanner motor.
FB H.P Drive
Current
10 ~ 1400 [mA] 530 [mA] 530 [mA]
FB Keep
Current
10 ~ 1400 [mA] 50 [mA] 50 [mA]
Adjust ADF
Motor
ADF Hopping
Drive Mono
Current
10 ~ 1400 [mA] 960 [mA] 960 [mA]
ADF Transfer
Drive Mono
Current
10 ~ 1400 [mA] 1050 [mA] 1050 [mA]

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
