Oki MC873dn - Page 115

45850101TH Rev.1
3-6
Oki Data CONFIDENTIAL
3. MAINTENANCE MENUS
Item1 Item2 Item3 Item4 Item5 Value
Default
value
ODA
Default
value
OEL
Default
value
JP
Notes
Password Scanner
Maintenance
Adjust Mech. Adjust ADF
Motor
ADF Hopping
Drive
300Color
Current
10 ~ 1400 [mA] 960 [mA] 960 [mA]
ADF Transfer
Drive
300Color
Current
10 ~ 1400 [mA] 1050 [mA] 1050 [mA]
ADF Hopping
Drive
600Color
Current
10 ~ 1400 [mA] 1180 [mA] 1180 [mA]
ADF Transfer
Drive
600Color
Current
10 ~ 1400 [mA] 1200 [mA] 1200 [mA]
ADF Keep
Current
10 ~ 1400 [mA] 200 [mA] 200 [mA]
Adjust CIS Adjust CIS simple
R continuous
G continuous
B continuous
All continuous
Only for engineering test
Sequentially light the designated RGB colors and check them during
calibration configuration duties.
Move the CIS to the standard position.
In the position moved to, sequentially light R, followed by G and B in
the same manner.
Light each color for approximately 3 seconds.
Display "Testing" during execution?
→
On the panel, display "CIS light testing" and "Cancel."
Check CIS 300dpi
600dpi
---Results Displayed---
CCD_SIG9_WID_H 0x000000
CCD_SIG2_WID_H 0x000000
Only for engineering test
Check CIS maintenance displays the exposure time at each
resolution.
When resolution is set, scanner calibration is conducted at that
resolution and the
following results are displayed:
Red-1
Red-2
Green-1
Green-2
Blue-1
Blue-2
Lsync
Note : CIS exposure time varies with resolution.
