45850101TH Rev.1
3-31
Display at the completion of density adjustment test
Upper display Lower display Details
OK / ERROR NAME DEN ADJ RESULT Displays only “OK” in the upper display
when no error occurs.
Displays an error name when errors
occur.
Displays “**** RESULT” corresponding to
a test executed in the lower display.
Errors of the density adjustment test
Error name displayed Contents
CALIBRATION ERR Abnormal end of the calibration of a sensor
DENS SENSOR ERR Detects an abnormal sensor output during the continuous
density detection.
DENS SHUTTER
ERR
Detects an abnormality when opening and closing the shutter
during the continuous density detection.
DENS ID ERR Detects the out of focus of the LED head or dirt due to ID failure.
Display Items of DENS ADJ RESULT
Upper display Lower display Details
Memory
LEV0 V/D OUT YMC V1=***H
V1DA=***H
V1=***H: Color density sensor output when
the LED current of the density sensor is
0[A]. [HEX]
V1DA=***:DA setting value of the LED
current of the density sensor at the color
density detection determined by the color
calibration of the density sensor. [HEX]
SRAM
LEV0 V/D OUT K V2=***H
V2DA=***H
V2=***H: Black density sensor output when
the LED current of the density sensor is
0[A]. [HEX]
V1DA=***:DA setting value of the LED
current of the density sensor at the black
density detection determined by the black
calibration of the density sensor. [HEX]
SRAM
LEV0 V/D OUT RD V3=***H
V3DA=***H
V3=***H: Detected voltage value when the
LED current of YMC density sensor is 0[A].
[HEX]
V3DA=***: DAC setting value at YMC
multiple points [HEX]
SRAM
LEV0 V/D OUT YMC V4=***H Value after subtracting V1 from the CMY
sensor output [HEX]
If a value after subtracting is a negative
value, it is regarded as ‘0’.
SRAM
LEV0 V/D OUT K V5=***H Value after subtracting V1 from the K
sensor output [HEX]
If a value after subtracting is a negative
value, it is regarded as ‘0’.
SRAM
H_DUTY DENS-K V1=***H S1=***H Not used SRAM
H_DUTY DENS-Y V1=***H S1=***H Not used SRAM
H_DUTY DENS-M V1=***H S1=***H Not used SRAM
H_DUTY DENS-C V1=***H S1=***H Not used SRAM
L_DUTY DENS-K V01=***HS01=***H 01-03:First processing for averaging density
04-06: Second processing for averaging
density
V0X: Density sense value [HEX]
S0X: Density detection value [HEX]
SRAM
V02=***HS02=***H
V03=***HS03=***H
V04=***HS04=***H
V05=***HS05=***H
V06=***HS06=***H
L_DUTY DENS-Y V01=***HS01=***H 01-03:First processing for averaging density
04-06: Second processing for averaging
density
V0X: Density sense value [HEX]
S0X: Density detection value [HEX]
SRAM
V02=***HS02=***H
V03=***HS03=***H
V04=***HS04=***H
V05=***HS05=***H
V06=***HS06=***H
To Next Page
